IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo

In stock
SKU
IPC-HFW2230M-AS-LED-B
Rating:
100% of 100
$74.00

IPC-HFW2230M-AS-LED-B

2MP Lite Full-color Fixed-focal Bullet Network Camera

> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs 2MP (1920 × 1080)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in LEDs, max LED distance: 20 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Abnormality detection: Motion detection, video tampering, scene changing, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 128 GB Micro   SD card

> 12V DC/PoE power support; 12V DC power output, max. current 165mA

> IP67 protection

>without Logo,English firmware
>100% original products manufactured by DAHUA

The delivery time is 25 working days usually, some times can complete early.

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo

IPC-HFW2230M-AS-LED-B

2MP Lite Full-color Fixed-focal Bullet Network Camera

> 2MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs 2MP (1920 × 1080)@25/30 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in LEDs, max LED distance: 20 m

> ROI, SMART H.264/H.265, flexible coding, applicable to various bandwidth and storage environments

> Rotation mode, DWDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Abnormality detection: Motion detection, video tampering, scene changing, no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, voltage detection

> Alarm: 2 in, 2 out; audio: 1 in, 1 out; supports max. 128 GB Micro   SD card

> 12V DC/PoE power support; 12V DC power output, max. current 165mA

> IP67 protection

>without Logo,English firmware
>100% original products manufactured by DAHUA

IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo System Overview



With upgraded H.265 encoding technology,  Lite series network camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better color image in the condition of low illumination. It supports SD card storage, dust-proof function, waterproof function and vandal-proof function, complying to the standards of IP67.

DAHUA Smart Shop solution

IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo Functions

Smart Codec

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.

Full-color

With high-performance sensor and large aperture lens, Dahua Full-color technology can display clear colorful image in the environment of ultralow illuminance. With this photosensitivity technology, the camera can capture more available light, and display more colorful image details.

Full-color Starlight

Image Flip

Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee the good image effect.

Motion Detection

When moving objects appear in the monitoring image, Dahua Motion Detection (General) technology triggers alarm or records.

Protection (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.



IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo Picture




IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo Dimensions




IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo Installation


IPC-HFW2230M-AS-LED-B - DAHUA DH-IPC-HFW2230M-AS-LED-B 2MP Lite Full-color Fixed-focal Bullet Network Camera With Rotation mode Abnormality detection Motion Detection Full-color technology IPC-HFW2230M-AS-LED-B without logo Technical Specifications

*********

Camera

Image Sensor

1/2.8” 2Megapixel progressive CMOS

Effective Pixels

1920 (H) × 1080 (V)

ROM

16 MB

RAM

128 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100000 s

Min. Illumination

0.002 Lux@F1.6

LED Distance

20 m (65.6 ft)

LED On/Off Control

Auto/Manual

LEDs Number

2

Lens

Lens Type

Fixed-focal

Mount Type

M12

Focal Length

3.6 mm

6 mm

Max. Aperture

3.6 mm: F1.6

6 mm: F1.6

Field of View

3.6 mm: Pan 87° × Tilt 46° × Diagonal 104°

6 mm: Pan 53° × Tilt 30° × Diagonal 60°

Iris Type

Fixed

Close Focus Distance

3.6mm: 1.2 m (3.9 ft)

6mm: 2.5 m (8.2 ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

3.6 mm

55.2 m

(181.1 ft)

22.1 m

(72.5 ft)

11.0 m

(36.1 ft)

5.5 m

(18.0 ft)

6 mm

82.8 m

(271.7 ft)

33.1 m

(108.6 ft)

16.6 m

(54.4 ft)

8.3 m

(27.2 ft)

Video

Video Compression

H.265; H.264; H.264B; MJPEG

Smart Codec

Yes

Video Frame Rate

Main stream:

1920 × 1080 (1 fps-25/30 fps)

Sub stream:

704 × 576 (1 fps-25 fps)

704 × 480 (1 fps-30 fps)

Stream Capability

2 streams

Resolution

1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 ×720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 32 kbps–6144 kbps
H.265: 12 kbps–6144 kbps

Day/Night

Color/B/W

BLC

Yes

HLC

Yes

WDR

DWDR

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest(RoI)

Yes (4 areas)

Smart IR

Yes

Image Rotation

0°/90°/180°/270° (Supports 90°/270° with 1080p resolution and lower.)

Mirror

Yes

Privacy Masking

4 areas

Network

Network

RJ-45 (10/100 Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP ; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; PPPoE; 802.1x; Bonjour

Interoperability

ONVIF(Profile S/Profile G);CGI; P2P; Genetec

User/Host

20

Edge Storage

FTP; SFTP; Micro SD Card (support max. 128 GB); NAS

Browser

IE: IE11 and earlier

Chrome: 42 and earlier

Firefox: 52 and earlier

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B

Port

Audio Input

1 channel (RAC port)

Audio Output

1 channel (RAC port)

Alarm Input

2 channels In: 5mA 5V DC

Alarm Output

2 channels Out: 300mA 12V DC

Power

Power Supply

12V DC/PoE (802.3af)

Power Consumption

< 10W

Environment

Operating Conditions

–40°C to +60°C (–40°F to +140°F)/less than ≤ 95% RH

Storage Temperature

–40°C to +60°C (–40°F to +140°F)

Protection Grade

IP67

Structure

Casing

Metal + plastic

Dimensions

194.1 mm × 96.4 mm × 89.5 mm (7.6" × 3.8" × 3.5") (L × W × H)

Net Weight

0.72 kg (1.6 lb)

Gross Weight

1.25 kg (2.8 lb)

***********

**
