LR2226-24ET-360 - DAHUA DH-LR2226-24ET-360 24-Port PoE Switch with 8-Port ePoE

In stock
SKU
LR2226-24ET-360
$278.99

LR2226-24ET-360

24-Port PoE Switch with 8-Port ePoE

> Supports long distance PoE transmission up to 800m with ePoE technology
> Layer-two web managed ePoE switch
> Port 1-8 support three self-adaptive transmission modes which are IEEE, E100 and E10
> Port 1-8 support both twisted-pair transmission and coaxial cable transmission
> Support web management: port management, 802.1Q VLAN, STP/RSTP, LACP, 802.1X, QoS
> Support PoE management, Green PoE, Legacy Support
> Conform IEEE802.3, IEEE802.3u, IEEE802.3ab/z and IEEE802.3X standards
Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.
Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

LR2226-24ET-360 - DAHUA DH-LR2226-24ET-360 24-Port PoE Switch with 8-Port ePoE

DH-LR2226-24ET-360 is a 24-Port web managed ePoE switch, which is able to realize PoE transmission over 800 meters Ethernet cable at the speed of 10Mbps, or 300 meters at the speed of 100Mbps. Besides, it supports PoE and PoC power supply technology, which has greatly simplified construction and wiring. Dahua ePoE technology offer a new way to accomplish long distance transmission between IP camera and network switch. It allows more flexible surveillance system design, improves reliability and saves construction and wiring cost.

LR2226-24ET-360 - DAHUA DH-LR2226-24ET-360 24-Port PoE Switch with 8-Port ePoE PICTURE

DAHUA DH-LR2226-24ET-360 24-Port PoE Switch with 8-Port ePoE

LR2226-24ET-360 - DAHUA DH-LR2226-24ET-360 24-Port PoE Switch with 8-Port ePoE DIAGRAM

LR2226-24ET-360 - DAHUA DH-LR2226-24ET-360 24-Port PoE Switch with 8-Port ePoE TECHNICAL SPECIFICATION

*********

Technical Specification

Model

DH-LR2226-24ET-360

Ethernet Port

2*10/100/1000 Base-T

2*1000 Base-X (Combo ports)

24*10/100 Base-T (PoE power supply)

PoE Power Consumption

Port1 and port 2 support Hi-PoE 60W

Each power≤30W, Total≤360W

PoE Protocol

IEEE802.3af, IEEE802.3at, Hi-PoE

Switching Capacity

8.8Gbps

Packet Forwarding Rate

6.55Mpps

Packet Buffer Memory

2.75Mb

Application Humidity

10%~90%

Power

AC100-240V, 50/60Hz

Lightning Protection

Common Mode 4KV

Differential Mode 2KV

Working Temperature

﹣10°C~55°C

Weight

3.12kg

Dimension(W×D×H)

440mm x300mm x44mm

Transmission Performance:

ePoE Power Supply Specifications (CAT)

Cable (m)

Bandwidth (Mbps)

PoE Load Capacity (W)

Hi-PoE Load Capacity (W)

Working Mode

100

100

25.5

53

IEEE/E100

200

100

25.5

47

E100

300

100

25.5

32

E100

400

10

23

26

E10

500

10

20

20

E10

800

10

13

13

E10

ePoE switch power supply voltage 51V

CAT5E/CAT6, max. DC resistance < 10Ω/100m

ePoE Power Supply Specifications (RG59 Coaxial Cable)

Cable (m)

Bandwidth (Mbps)

PoE Load Capacity (W)

Hi-PoE Load Capacity (W)

Working Mode

100

100

25.5

52

IEEE/E100

200

100

25.5

48

E100

300

100

25.5

30

E100

400

100

20

23

E100

500

10

16

16

E10

800

10

10

10

E10

1000

10

8

8

E10

ePoE switch power supply voltage 51V.

RG-59, max. DC resistance < 5Ω/100m.

Service Characteristics

Model

DH-LR2226-24ET-360

System

Username / password: admin/User Define

IP Address :192.168.1.110/24

PoE Budget

360W

MAC Table

4K

VLAN

802.1Q Standard VLAN

Spanning Tree

STP, RSTP

Port Aggregation

Static link aggregation, LACP

Mirroring

Support many-to-one port mirroring

DHCP

Support DHCP-Client

Long Distance Mode

Extend the maximum distance from 100m to 800m

Flow Control

Support half-duplex based on back pressure type control;

Support full duplex based on PAUSE frame

Security Features

Hardware supports IP+MAC binding based on port

Support IEEE802.1x port authentication

System Maintenance

one-key recovery of default

Support the updated packet upload

Support system logs

QoS

Support high and low priority, WRR

Support 802.1P, DSCP

Support priority according to protocol

Network Management

WEB(http and https protocol)

Support SNMP V1/V2C/V3

PoE Management

Support PoE power consumption, PoE on/off of IPC configura-tion, power down when exceeding the value of overload power

Support PoE event statics

Support Green PoE

Support Legacy Support

Accessories

SFP Module

Description

PFT3950

1.25G 850nm,500m,LC, Multi-mode

PFT3960

1.25G 1310/1550nm,20km,LC, Single-mode

PFT3970

1.25G 1550/1310nm,20km,LC, Single-mode

EoC (Ethernet over Coax)

Description

LR1002

1*10/100 Mbps Base-TX + 1*BNC

RG59 coaxial cable:

400m/100Mbps, 1000m/10Mbps

***********

*********

**

**
