IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2

In stock

SKU

BWIPC-HDBW2531R-ZS-S2

Be the first to review this product

$115.68

IPC-HDBW2531R-ZS-S2

5MP Lite IR Vari-focal Dome Network Camera

> 5MP, 1/2.7” CMOS image sensor,

low illuminance, high image definition

> Outputs 2688×1520 (2688×1520) @ 25/30 fps,

and supports max. 5MP (2592×1944) @ 20 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max IR distance: 40 m

> ROI, SMART H.264/H.265, flexible coding,

applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC,

digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering,

no SD card,SD card full, SD card error, network disconnected,

IP conflict, illegal access, voltage detection

> Supports max. 256 GB Micro SD card

> 12V DC/PoE power support

> IP67, IK10 protection grade

> dahua Logo,English firmware
> 100% original products manufactured by DAHUA

The delivery time is 25 working days .

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Skip to the end of the images gallery

Skip to the beginning of the images gallery

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2

IPC-HDBW2531R-ZS-S2

5MP Lite IR Vari-focal Dome Network Camera

> 5MP, 1/2.7” CMOS image sensor, low illuminance, high image definition

> Outputs 2688×1520 (2688×1520) @ 25/30 fps,

and supports max. 5MP (2592×1944) @ 20 fps

> H.265 codec, high compression rate, ultra-low bit rate

> Built-in IR LED, max IR distance: 40 m

> ROI, SMART H.264/H.265, flexible coding,

applicable to various bandwidth and storage environments

> Rotation mode, WDR, 3D DNR, HLC, BLC,

digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire

> Abnormality detection: Motion detection, video tampering,

no SD card,SD card full, SD card error, network disconnected,

IP conflict, illegal access, voltage detection

> Supports max. 256 GB Micro SD card

> 12V DC/PoE power support

> IP67, IK10 protection grade

> ,English firmware
> 100% original products manufactured by DAHUA

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2 System Overview

DAHUA Smart Shop solution

With updraded H.265 encoding technology, Dahua Lite series camera has efficient video encoding capacity, which saves bandwidth and storage space. This camera adopts the latest starlight technology and displays better colorful image in the environment of low illumination. It supports SD card storage, waterproof function, dust-proof function and tamper-proof function, complying to the standards of IP67 and IK10.

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2 Functions

Smart(H.265+ & H.264+)

Adopting advanced algorithm of auto stream control according to the environment, Dahua smart encoding technology realizes the higher efficiency than (H.265 & H.264 ), providing high-quality video, and reducing the cost of storage and transmission.

Wide dynamic range (WDR)

adopts advanced Wide Dynamic Range (WDR) technology. You can get clear details in the environment of strong brightness contrast. In high brightness and back- light environment, bright region and dark region with strong light source, you can also get clear images.

starlight

Starlight

Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee the good image effect.

Intelligent Video Analysis (IVS)

With advanced video algorithm, camera supports intelligent detection, such as tripwire and intrusion and so on.

Protection (IP67, IK10, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. IK10: The enclosure can stand the punch more than 5 times from a 5 kg hammer falling from a height of 40 m (Impact energy is 20J). Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2 Picture

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2 Dimension

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2 Installation

IPC-HDBW2531R-ZS-S2 – DAHUA DH-IPC-HDBW2531R-ZS-S2 5MP Lite IR Vari-focal Dome Network Camera with IP67,12V DC/PoE power support 2.7~13.5mm varifocal Intelligent Video Analysis IPC-HDBW2531R-ZS-S2 Specification

Technical Specifications

***

Camera

Image Sensor

1/2.7” 5Megapixel progressive CMOS

Effective Pixels

2592(H) x1944(V)

RAM/ROM

512MB/32MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.02Lux/F1.6( Color,1/3s,30IRE)

0.2Lux/F1.6( Color,1/30s,30IRE)

0Lux/F1.6(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 30m(98ft)

IR On/Off Control

Auto/ Manual

IR LEDs

Lens

Lens Type

Motorized(-ZS),Manual(-VFS)

Mount Type

Board-in

Focal Length

2.7mm~13.5mm

Max. Aperture

F1.6

Angle of View

H:95°~27°, V:70°~20°

Focus Control

Motorized(-ZS),Manual(-VFS)

Close Focus Distance

0.3m

DORI Distance

Lens

Detect

Observe

Recognize

Identify

64m(210ft)

26m(85ft)

13m(43ft)

6m(20ft)

222m(728ft)

89m(292ft)

44m(144ft)

22m(72ft)

PTZ

Pan/Tilt Range

Pan:0° ~355° ;Tilt:0° ~75° ;Rotation:0° ~355°

Intelligence

Event Trigger

Motion detection, Video tampering,Scene changing,Network disconnection,IP address conflict,Illegal acess,Storage anomaly

IVS

Tripwire, Intrusion

Video

Compression

H.265+/H.265/H.264+/H.264

Smart Codec

Support H.265+/h.265+

Streaming Capability

2 Streams

Resolution

5M(2592×1944)/4M(2688x1520)/(2560×1440)/(2304x1296)/1080P(1920x1080)/SXGA(1280×1024)/1.3M(1280× 960)/720P(1280×720)/D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240)

Frame Rate

5M (1 ~ 15fps)/3M(1 ~ 25/30fps)

D1/CIF(1 ~ 20/25fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.265: 12K ~ 8448Kbps

H.264: 32K ~ 10240Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization(EIS)

N/A

Smart IR

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

N/A

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

HTTP;HTTPS;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;Qos;UPnP;NTP;Bonjour;IEEE802.1x;Multicast;ICMP;IGMP;TLS;RTCP

Interoperability

ONVIF Profile S&G,API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users / 20 Users

Edge Storage

NAS

Local PC for instant recording

Micro SD Card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

N/A

Audio Interface

N/A

RS485

N/A

Alarm

N/A

Electrical

Power Supply

DC12V PoE (802.3af)(Class 0)

Power Consumption

<9.5W(-ZS), <7.5W(-VFS)

Environmental

Operating Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Strorage Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

φ122mm×88.9mm(4.80''x3.50'')

Net Weight

0.4Kg (0.88lb)

Gross Weight

0.54Kg(1.19lb)

*******
