Camera

Image Sensor

Panoramic network camera: 1/1.8”CMOS PTZ camera: 1/1.8”CMOS

Max. resolution

Panoramic network camera: 8192×1800

PTZ camera: 2560×1440

ROM

Panoramic network camera:4GB
PTZ camera:4GB

RAM

Panoramic network camera:4GB
PTZ camera:1GB

Electronic Shutter Speed

Panoramic network camera: 1/3 s-1/100000 s, manual or auto adjust

PTZ Camera: 1/1 s-1/300000 s, manual or auto adjust

Min. Illumination

Panoramic network camera:

0.001Lux(colour);0.0001Lux(black);

PTZ camera:

0.001Lux(colour);0.0001Lux(black);0Lux(IR on)

S/N Ratio

Panoramic network camera:51db
PTZ camera:51.5db

IR Distance

Panoramic network camera: — PTZ camera: ≥ 100 m (328ft) (IR on)

IR On/Off Control

Auto/Manual/Zoomprio

IR LEDs Number

Panoramic network camera：— PTZ camera: 4

Lens

Lens Type

Panoramic network camera:Fixed-focal

PTZ camera:Motorized vari-focal

Mount Type

Panoramic network camera:M16

PTZ camera: Core interface

Focal Length

Panoramic network camera 2.8 mm

PTZ camera: 5.4mm~135mm, 25x optical zoom

Max. Aperture

Panoramic network camera: F1.0

PTZ camera: F1.6~F4.0

Field of View

Panoramic network camera:Horizontal: 360° Vertical: 85°

PTZ camera:

Horizontal:3.5°~58°

Vertical: 2°~35°

Diagonal: 2°~64°

Iris Type

Panoramic network camera: Fixed aperture PTZ camera: Auto

Close Focus Distance

Panoramic network camera: 1.4m(4.6ft)

PTZ camera:0.5m~7m(1.64ft~22.96ft)

DORI Distance

Detect

Observe

Reconize

Identify

Panoramic network camera

57.9m

(189.96ft)

23.2m

(76.11ft)

11.6m

(38.05ft)

5.8m

(19.02ft)

PTZ camera

1688m

(5538.05ft)

675m

(2214.56ft)

337m

(1105.64)

168m

(551.18ft)

Smart Event

IVS

Panoramic network camera: Intrusion, tripwire

PTZ camera:Tripwire, intrusion, fast moving (the three functions support the classification and accurate detection of vehicle and human); parking detection, loitering detection, and people gathering.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG

Smart Codec

Smart H.264+

Smart H.265+

AI Coding

AI H.265;AI H.264

Video Frame Rate

Panoramic network camera:

Main stream(8192×1800@1~30fps),

Sub Stream(2048×452@1~30fps),

Third Stream(3840×832@`~30fps)

PTZ camera:

Main stream(2688×1520@1~30fps),

Sub Stream(704×480@1~30fps),

Third Stream(1920×1080@1~30fps)

Stream Capability

3 Streams

Resolution

Panoramic network camera:

Main stream:

8192×1800;7680×1680;5760×1264;4096×900

Sub Stream:2048×452

Third Stream:3840×832;2560×560

PTZ camera:

Main stream:

2560×1440;1920×1080;1280×960;1280×720

Sub Stream:704×576;352×288

Third Stream:1920×1080;1280×960;1280×720

Bit Rate Control

Panoramic network camera: CBR/VBR

PTZ camera:CBR/VBR

Video Bit Rate

Panoramic network camera:

H.264:3584kbps ~18176Kb/S

H.265:1280kbps ~11008 Kb/S

PTZ camera:

H.264:2816Kbps ~ 13056Kbps

H.265:1024Kbps ~ 7936Kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

Panoramic network camera:DWDR

PTZ camera: WDR (120 dB )

White Balance

Panoramic network camera:Auto/Natural/street lamp/outdoor/manual/regional Custom

PTZ camera: Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street lamp

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

Disable/Enable

Region of Interest (RoI)

Yes (4 areas)

Electronic Image stabilization(EIS)

Panoramic network camera: — PTZ camera: Yes

Smart IR

Panoramic network camera: — PTZ camera: Yes (Adjusted by user.)

Defog

Panoramic network camera: — PTZ camera: Yes

Image Rotation

0°/180°(PTZ camera)

Privacy masking

Panoramic network camera: 4 areas PTZ camera: 8 areas

Audio

Audio Compression

PCM/G.711A/G.711Mu/G.726/AAC/G.723

Network

Network

RJ-45 (10/100/1000 Base-T)

Protocol

IPv4;IPv6;HTTP;HTTPS;TCP; UDP;ARP;RTP ;

RTSP;RTCP; RTMP;SMTP;FTP;SFTP;DHCP;DNS;DDNS; QoS;UPnP;NTP;Multicast;ICMP;IGMP;NFS;SAMBA;PPPoE;802.1x;SNMP

Interoperability

ONVIF (Profile S/Profile G); CGI; Milestone

User/Host

9 (Total bandwidth: 176M)

Edge Storage

Micro SD card (support max. 512GB);FTP;SFTP;NFS;SMB

Management Software

DSS

PTZ Dome

Pan Range

Pan: 0° to 360° endless
Tilt: –10° to 90°, auto flip 180

Manual Control Speed

Pan: 120°/s
Tilt: 50°/s

Positioning Accuracy

Pan: 0.1°
Tilt: 0.1°

Remote Lens Reset

Yes

Preset

300

Tour

8 Tour (up to 32 preset per tour)

Pattern

5 patterns

Scan

5

Power-off Memory

Yes

Idle Motion

Preset/Pattern/Tour/Scan

Time Task

Yes

Three-dimensional Positioning

Yes

PTZ Limit

Yes

Position Display

Yes

Information Display

Yes

Time Display

Yes

Port

Audio Input

2 channels (terminal)

Audio Output

1 channels (terminal)

Alarm Input

3 channels in: 5mA 3V–5V DC

Alarm Output

2 channels out: 1,000mA 30V DC/500mA 50V DC

Power

Power Supply

DC36V (±50%)

Power Consumption

Basic: 35 W (36V DC)

Max. (Basic power consumption + WDR + intelligence on + IR on + PTZ operation ): 45 W (36V DC)

Environment

Operating Temperature

--40°C to +60°C (-104°F to +140°F)

Operating Humidity

≤95%

Storage Temperature

-40°C to +70°C (-104°F to +158°F)/Less than 95% RH

Ingress Protection

IP67

Structure

Enclosure

Metal + Plastic

Product Dimensions

Φ280mm × 326 mm (Φ11" × 12.8")

Packaging Dimensions

394mm×352mm×468mm(15.5"×13.9"×18.4")

Net Weight

7kg (15.43 lb)

Gross Weight

10.4kg (22.93 lb)
