IPC-PFW81642-A180- DAHUA DH-IPC-PFW81642-A180 4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera with EPTZ Vehicle Density

IPC-PFW81642-A180

4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera

> 4x4-MP 1/1.8" CMOS image sensor, low luminance, and high definition image.
> Outputs max. 16 MP (5520 × 2700)@25/30 fps.
> H.265 codec, high compression rate, ultra-low bit rate.
> Three streams for HD video display.
> Built-in IR LED, and the max. illumination distance is 30 m.
> 3D NR, HLC, BLC, digital watermarking, applicable to various monitoring scenes.
> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.
> Alarm: 2 in, 2 out; audio: 1 in, 1 out; RS-485; BNC; supports max. 256 G Micro SD card.
> 12 VDC/24 VAC/PoE power supply, easy for installation.
> IP67 and IK10 protection.

WizMind Series

 WizMind is a wide range of project-oriented products that adopt industry-leading deep learning algorithms, such as IPC, NVR, PTZ, XVR, thermal camera and software platform. Focusing on customers’ needs, WizMind provides precise and reliable and comprehensive AI products for verticals.
Precise: Powered by AI chip and deep learning algorithms, WizMind delivers accurate detection and recognition of human and vehicle, enabling users to rapidly and precisely act on what really matters. In addition, it provides accurate and effective AI search to locate targets, and various human-based data for business analysis.
Reliable: Strict component selection to ensure the high product reliability. With thorough testing of front-end cameras, back-end device and platform, WizMind injects reliability into all of its solutions.
Comprehensive: Focusing on human and vehicle, WizMind provides various applications solutions such as face recognition, privacy protection, video metadata, stereo analysis, ANPR, illegal parking, etc. Moreover, WizMind combines deep learning algorithm with thermal imaging technology to help users achieve ultra-long distance monitoring in harsh environments, highly accurate non-contact temperature measurement with only ±0.3℃ temperature difference, and early detection of fire.

IPC-PFW81642-A180- DAHUA DH-IPC-PFW81642-A180 4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera with EPTZ Vehicle Density System Overview

Launched by Dahua Technology, Dahua WizMind is a full portfolio of solutions composed of project-oriented products including IPC, IVSS,NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer's requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals.The splicing camera supports a 180° panoramic view and 4-channel hardware splicing to realize HD panoramic surveillance. The camera supports crowd situation analysis, vehicle situation analysis, and perimeter protection. It is widely applied in various scenes such as squares, airports, safe city, and traffic.

IPC-PFW81642-A180- DAHUA DH-IPC-PFW81642-A180 4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera with EPTZ Vehicle Density Functions

Panoramic Splicing

With advanced splicing algorithm, Dahua Panoramic Splicing technology deletes overlapped area and splices multiple images to be a complete panorama. The field of view of the spliced image can be up to 360°, which largely improves surveillance efficiency and user experience. Generally, after splicing, the field of view of four-sensor camera can be 180°, and the field of view of eight-sensor camera can be 360°.

Perimeter Protection

With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced..

Crowd Density

With deep learning algorithm, Dahua Crowd Density technology can detect the crowd density on the image, and display it on heat map; it can detect people quantity and density in selected area and set threshold. When the number or density is larger or smaller than the threshold, it triggers linkage.

Vehicle Density

With deep learning algorithm, Dahua Vehicle Density technology analyses the vehicle situation in the image, such as vehicle number in selected area. You can set threshold, and when the number is larger or smaller than the threshold, it triggers linkage..

Cyber Security

Dahua network cameras employ a series of security technologies, including security authentication and authorization, access control protocols, trusted protection, encrypted transmission and encrypted storage. These technologies improve the camera's defense against external cyber threats and prevent malicious programs from compromising the device.

Perimeter Protection

With deep learning algorithm, Dahua Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

EPTZ

With advanced target detection and tracking algorithms, Dahua EPTZ technology can simultaneously zoom in and track multiple humans and vehicles that trigger alarms. It provides rich details and a panoramic view at the same time..

IPC-PFW81642-A180- DAHUA DH-IPC-PFW81642-A180 4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera with EPTZ Vehicle Density  Picture

IPC-PFW81642-A180- DAHUA DH-IPC-PFW81642-A180 4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera with EPTZ Vehicle Density  Dimension

IPC-PFW81642-A180- DAHUA DH-IPC-PFW81642-A180 4x4MP WizMind Multi-Sensor Splicing Panoramic Bullet Network Camera with EPTZ Vehicle Density  Installation

********

***********

*
