PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237

In stock

SKU

PSDW81642ML-A360-D237

Be the first to review this product

$2,687.70

PAL/NTSC

Brand

Qty

PSDW81642ML-A360-D237

8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera

> Panoramic: Eight 1/1.8'' 2 Megapixel progressive scan CMOS

> PTZ: One 1/1.8'' 2 Megapixel progressive scan CMOS

> Support 360-degree panoramic view

> Starlight+ technology

> support Smart H265+/H264+ encoding

> Day/Night (ICR); 3D NR; AWB; AGC; BLC

> IR distance up to 220 m

> Smart tracking

> Tripwire

> Intrusion

> without Logo,English firmware
> 100% original products manufactured by DAHUA

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Skip to the end of the images gallery

Skip to the beginning of the images gallery

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237

PSDW81642ML-A360-D237

8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera

> Panoramic: Eight 1/1.8'' 2 Megapixel progressive scan CMOS

> PTZ: One 1/1.8'' 2 Megapixel progressive scan CMOS

> Support 360-degree panoramic view

> Starlight+ technology

> support Smart H265+/H264+ encoding

> Day/Night (ICR); 3D NR; AWB; AGC; BLC

> IR distance up to 220 m

> Smart tracking

> Tripwire

> Intrusion

> without Logo,English firmware
> 100% original products manufactured by DAHUA

DAHUA PSDW81642ML-A360-D237,DAHUA DH-PSDW81642ML-A360-D237,PSDW81642ML-A360-D237,DAHUA DH-PSDW81642ML-A360-D237,DH-PSDW81642MLP-A360-D237,DH-PSDW81642MLN-A360-D237,PTZ WizMind Network Camera,Multi-Sensor Panoramic Camera,DAHUA Starlight Camera

wizmind AI

WizMind Series

WizMind is a wide range of project-oriented products that adopt industry-leading deep learning algorithms, such as IPC, NVR, PTZ, XVR, thermal camera and software platform. Focusing on customers’ needs, WizMind provides precise and reliable and comprehensive AI products for verticals.
Precise: Powered by AI chip and deep learning algorithms, WizMind delivers accurate detection and recognition of human and vehicle, enabling users to rapidly and precisely act on what really matters. In addition, it provides accurate and effective AI search to locate targets, and various human-based data for business analysis.
Reliable: Strict component selection to ensure the high product reliability. With thorough testing of front-end cameras, back-end device and platform, WizMind injects reliability into all of its solutions.
Comprehensive: Focusing on human and vehicle, WizMind provides various applications solutions such as face recognition, privacy protection, video metadata, stereo analysis, ANPR, illegal parking, etc. Moreover, WizMind combines deep learning algorithm with thermal imaging technology to help users achieve ultra-long distance monitoring in harsh environments, highly accurate non-contact temperature measurement with only ±0.3℃ temperature difference, and early detection of fire.

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237 System Overview

WizMind is a full portfolio of solutions composed of project-oriented products including IPC, NVR, PTZ, XVR, Thermal and software platform which adopts industry-leading deep learning algorithms. Focusing on customer's requirements, WizMind provides precise, reliable and comprehensive AI solutions for verticals DAHUA DH-PSDW81642M-A360

Starlight panoramic HD network camera, with all-in-one design, provides a 360°panorama and region of interest details at the same time. The panoramic network combines 8 sensors working in tandem to realize 360°panoramic surveillance; all-in-one module and high-speed PTZ camera provides the function of quick position details. In addition, with video analytic algorithm and multi-target track algorithm, the camera can automatically or manually detect tripwire and intrusion of mutiple targets in detection area, output alarm signal, and then link PTZ for smart tracking. With these excellent features, the camera can meet higher security requirements..

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237 Functions

True Day/Night

A day/night mechanical IR cut filter makes this camera ideal for applications with fluctuating lighting conditions, delivering color images during the day and automatically switching to monochrome as the scene darkens.

Starlight Technology

Featured with Dahua Starlight Technology, the camera is ideal for applications with challenging light conditions. Its low light performance delivers usable video with minimal ambient light. Even in extreme low light conditions, Starlight Technology is capable of delivering color images in nearly complete darkness.

Crowd map

1. The crowd map is displayed on panorama. 2. Customized ROIs setting, people counting overlay and people thresh old alarm. 3. Global crowd density threshold setting and alarm. 4. Alarm linkage for global crowd density threshold and area people threshold (Arm period, record, sending E-mail and snapshot).

Tripwire detection and intrusion detection

With advanced CNN algorithm, the detection distance,and the accuracy rate and timely rate of linkage track are much improved.

Smart tracking

1. Panoramic channel supports manual position, frame selection zoom position.

2. Manual track.

3. Auto track after tripwire and intrusion are triggered.

4. Smart tracking after crowd map alarm is triggered.

Tripwire detection and intrusion detection

With advanced CNN algorithm, the detection distance,and the accuracy rate and timely rate of linkage track are much improved.

DAHUA DH-PSDW81642M-A360 DAHUA PSDW81642ML-A360-D237,DAHUA DH-PSDW81642ML-A360-D237,PSDW81642ML-A360-D237,DAHUA DH-PSDW81642ML-A360-D237,DH-PSDW81642MLP-A360-D237,DH-PSDW81642MLN-A360-D237,PTZ WizMind Network Camera,Multi-Sensor Panoramic Camera,DAHUA Starlight Camera

DAHUA DH-PSDW81642M-A360

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237 Picture

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237 Dimension

PSDW81642M-A360

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237 Installation

PSDW81642ML-A360-D237- DAHUA DH-PSDW81642ML-A360-D237 8x2MP Multi-Sensor Panoramic + PTZ WizMind Network Camera With 360-degree panoramic view Smart tracking Starlight technology PSDW81642ML-A360-D237 Specification

Technical Specifications

*****

Camera

Image Sensor

1/1.8”4Megapixel progressive CMOS

Max. Resolution

8192 (H) × 2700 (V)

ROM

Panoramic network camera: 4 GB
PTZ camera: 32 GB

RAM

Panoramic network camera: 8 GB
PTZ camera: 4 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

Panoramic network camera:
0.001 Lux (Color); 0.0001 Lux (B/W)
PTZ camera:
0.001 Lux (Color); 0.0001 Lux (B/W); 0 Lux (IR on)

S/N Ratio

> 56 dB

Illumination Distance

PTZ camera:
≥ 400 m (1312 ft) (IR LED)

Illuminator On/Off Control

Auto/Manual/Zoomprio

Illuminator Number

7 (IR LED)

Pan/Tilt/Rotation Range

Pan: 0° to 355°
Tilt: –20° to 70°
Rotation: 0°–355°

Lens

Lens Type

Panoramic network camera: Fixed-focal
PTZ camera: Vari-focal

Mount Type

Panoramic network camera: M12
PTZ camera: Module

Focal Length

Panoramic network camera: 2.8 mm
PTZ camera: 5.6 mm–223 mm

Max. Aperture

Panoramic network camera: F1.6
PTZ camera: F1.35–F4.8

Field of View

Panoramic network camera:
Horizontal: 270°

Vertical: 111°
PTZ camera:
Horizontal: 2.27°–61.4°
Vertical: 1.3°–35.99°
Diagonal: 2.62°–68.18°

Iris Type

Panoramic network camera: Fixed
PTZ camera: Auto

Close Focus Distance

Panoramic network camera: 1.4 m (4.6 ft)
PTZ camera: 500 mm–2000 mm (19.7"–78.7") (T to W)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

Panoramic network camera

57.9 m

(190.0 ft)

23.2 m

(76.1 ft)

11.6 m

(38.1 ft)

5.8 m

(19.0 ft)

PTZ camera

2873.1 m (9426.2 ft)

1149.2 m (3770.3 ft)

574.6 m (1885.2 ft)

287.3 m (942.6 ft)

Professional, intelligent

IVS (Perimeter Protection)

Tripwire; intrusion

Crowd Distribution Map

Crowd map, global crowd density; crowd density in area; people counting in area; smart track for crowd density exception

Vehicle Density

Parking upper limit; traffic congestion alarm

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Smart Codec

Smart H.264+

Smart H.265+

Video Frame Rate

Panoramic network camera:
Main stream: 8192 × 2700 @1–25/30 fps
Sub stream 1: 2048 × 680 @1–25/30 fps
Sub stream 2: 3840 × 1248 @1–25/30 fps
PTZ camera:
Main stream: 2560 × 1440 @1–25/30 fps
Sub stream 1: 704 × 480 @1–25/30 fps
Sub stream 2: 1920 × 1080 @–25/30 fps

Stream Capability

3 streams

Resolution

Panoramic network camera:
Main stream: 8192 × 2700; 7680 × 2520; 5760 × 1896; 4096 × 1360
Sub stream 1: 2048 × 680; 1600 × 532; 1280 × 420
Sub stream 2: 3840 × 1248; 2560 × 840
PTZ camera:
Main stream: 2560 × 1400; 2048 × 1536; 1920 × 1080; 1280 × 960; 1280 × 720
Sub stream 1: 704 × 576/704 × 480; 352 × 288/352 × 240
Sub stream 2: 1920 × 1080; 1280 × 960; 1280 × 720

Bit Rate Control

CBR/VBR

Video Bit Rate

Panoramic network camera:
H.264: 127 kbps– 65536 kbps
H.265: 50 kbps– 65536 kbps
PTZ camera:
H.264: 32 kbps– 17152 kbps
H.265: 12 kbps– 10240 kbp

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

Panoramic network camera: DWDR
PTZ camera: 120 dB

Scene Self-adaptation

Yes

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Panoramic network camera: Yes (4 areas)
PTZ camera: Yes (4 areas)

Electronic Image Stabilization (EIS)

Panoramic network camera: Not support
PTZ camera: Yes

Smart Illumination

Yes

Defog

Panoramic network camera: Not support
PTZ camera: Optical defog

Flip

Panoramic network camera: Not support
PTZ camera: 180°

Privacy Masking

Panoramic network camera: 4 areas
PTZ camera: 8 areas

Audio

Audio Compression

PCM;G.711A;G.711Mu;G.726;AA;G.723

Alarm

Alarm Event

No SD card; SD card full; SD card error; SD card service life warning; network disconnection; IP conflict; illegal access; motion detection; video tampering; tripwire; intrusion; scene changing; audio detection; intensity change; voltage detection; external alarm; safety exception; crowd congestion; vehicle congestion; parking upper limit

Audio Sampling

8 KHz; 16 KHz; 32 KHz; 48 KHz; 64 KHz

Network

RJ-45 (10/100/1000 Base-T)

SDK and API

Yes

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; Milestone;Genetec

User/Host

20 (Total bandwidth: 1000 M)

Storage

Micro SD card (support max. 256 G); FTP; SFTP; NFS; SMB

Browser

IE: IE9; IE10; IE11
Chrome: 42 and earlier
Firefox: 52 and earlier

Management Software

EVS;NVR5X-I;IVSS;DSS Pro;M70;Milestone;Genetec

PTZ Dome

Pan Range

Pan: 0° to 360° endless

Tilt: –12° to 90°, auto flip 180

Manual Control Speed

Pan: 240°/s

Tilt: 100°/s

Remote Lens Reset

Yes

Remote PTZ Reset

Yes

Preset

300

Tour

8 (up to 32 presets per tour0)

Pattern

Scan

Power-off Memory

Yes

Idle Motion

Preset/Pattern/Tour/Scan

Time Task

Yes

Three-dimensional Positioning

Yes

PTZ Limit

Yes

Position Display

Yes

Information Display

Yes

Time Display

Yes

Certifications

CE-LVD: EN62368-1

CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU

FCC: 47 CFR FCC Part 15, Subpart B

UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

RS-485

1 (baud rate range: 1200 bps–115200 bps); reserved

Audio Input

2 channels (terminal)

Audio Output

2 channels (terminal)

Alarm Input

7 channels in: 5mA 3V–5V DC

Analog Output

1 channel (CVBS outputs, NBC port)

Optical Module Specification

SFP optical module, single mode, single fiber 20KmTX-1310nm/RX-1550nm

Optical Fiber

Optical Fiber Module Type

Gigabit SFP optical module, single mode, single fiber TX-1550nm/RX-1310nm

Alarm Output

3 channels out: 1,000mA 30V DC/500mA 50V AC

SDI

Yes

Power

Power Supply

36V DC

Operating Voltage

36V DC (±50%)

Power Consumption

Basic power consumption: 33.7W (36V DC)
Max. power consumption (Basic power consumption + WDR + intelligent functions enabled + IR on + PTZ operation): Panoramic network camera: 71.9W (36V DC); PTZ camera: 5.4W

Environmental

Operating Conditions

–40°C to +70°C (–40°F to +158°F)

Storage Temperature

5°C–40°C (41°F–104°F)(The temperature difference of each day is within 15°C/59°F)

Protection Grade

IP66; IK10 (optional)

Structure

Casing

Metal + Plastic

Dimensions

Φ383 mm×389.8 (Φ15.1" × 15.3")

Box Dimensions

500 mm × 500 mm × 658 mm (19.7" × 19.7" × 25.9")

(L × W × H)

Net Weight

14.7 kg (32.4 lb)

Gross Weight

19.8 kg (43.7 lb)

Installation

Wall mount; ceiling mount; pole mount

Power Adapter

Standard

Lens

Standard

Power Output

12V DC power output, max. current 165mA

Others

Position

GPS/BDS

***

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

***

*DAHUA PSDW81642ML-A360-D237,DAHUA DH-PSDW81642ML-A360-D237,PSDW81642ML-A360-D237,DAHUA DH-PSDW81642ML-A360-D237,DH-PSDW81642MLP-A360-D237,DH-PSDW81642MLN-A360-D237,PTZ WizMind Network Camera,Multi-Sensor Panoramic Camera,DAHUA Starlight Camera

More Information
Wired/Wireless	Wired
Outdoor use	Outdoor use
Focal Type	Motorized Zoom
Day/Night	Low light
Factor	Dome
Max Resolution	8 MP
