TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo

In stock
SKU
TPC-BF2221-T
$1,198.87

TPC-BF2221-T

Thermal Network Hybrid Bullet Camera

> 256x192 VOx uncooled thermal sensor technology
> Athermalized lens (thermal camera), focus-free
> 1/2.8” 2Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Support temperature measurement
> Support fire detection & alarm
> Built-in 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePOE

> without Logo,English firmware
> 100% original products manufactured by DAHUA

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo

TPC-BF2221-T

Thermal Network Hybrid Bullet Camera

> 256x192 VOx uncooled thermal sensor technology
> Athermalized lens (thermal camera), focus-free
> 1/2.8” 2Megapixel progressive scan CMOS
> Support ROI, motion detection, color palettes
> Support temperature measurement
> Support fire detection & alarm
> Built-in 2/2 alarm in/out
> Micro SD memory, IP67, PoE, ePOE

> without Logo,English firmware
> 100% original products manufactured by DAHUA

TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo OVERVIEW

Featuring a dual lens Pan/Tilt/Zoom (PTZ) camera, this series provides an all-in-one solution that is especially beneficial for long distance video surveillance in outdoor applications. Together with Dahua Thermal and Starlight technology, the camera’s long range capabilities are able to be utilized even at night. The series combines one thermal camera for monitoring in total darkness and one camera with Starlight functionality and a motorized lens for confirming details up close.

Network Positioning SystemEntrance_Exit_Control_For_Vehicles_outline

icctvzone Thermal Cameras

TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo FUNCTIONS

Uncooled Vox Technology

Dahua thermal cameras use uncooled Vox sensor technology. Their small size and better performance make them a cost-effective solution for thermal security.

High Sensitivity

High thermal sensitivity (<40mK) allows cameras to capture more image details and temperature difference information.

Fire Detection & Alarm

With built-in fire detection functionality, the camera has the ability to detect fires from long range. Because thermal cameras are sensitive to temperature, they provide higher fire detection accuracy than standard cameras, making them particularly fit for applications such as forest fire prevention.

Temperature Measurement

Dahua thermal cameras (-T models) provide remote temperature monitoring functionality with the ability to set temperature threshold alarms. Object temperatures can be monitored in daytime or at night,making them ideal for usage in power plant or oil extraction applications where overheating can be dangerous. When the temperature exceeds the set threshold, an alarm is triggered. The temperature range is between -20 °C to 550 °C (-4°F to 1022 °F).

Intelligent Video System (IVS)

IVS is a built-in video analytics algorithm that delivers intelligent functions to monitor a scene for tripwire violations, intrusion detection, and abandoned or missing objects. A camera with IVS quickly and accurately responds to monitoring events in a specific area.

Environmental

With a temperature range of -40 °C to +70 °C, the camera is designed for extreme temperature environments. Subjected and certified to rigorous dust and water immersion tests, the IP66 rating makes it suitable for demanding outdoor applications. For enviorments with rain, sleet, snow and fog, an integrated wiper(optional) provides users with clear visibility at all times.

Protection

The camera Supporting wide range voltage input(100–300V AC), suitable for the most unstable conditions for outdoor applications. Its 6 kV lightning rating provides effective protection for both the camera and its structure against lightning.

TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo Picture

TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo Dimension



TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo

Installation



TPC-BF2221-T - DAHUA DH-TPC-BF2221-T Thermal Network Hybrid Bullet Camera With DH-TPC-BF2221P-T Support ROI, motion detection, color palettes Support temperature measurement Support fire detection & alarm DH-TPC-BF2221N-T without logo Specification



Technical Specifications

******

Technical Specification

Structure

Multi-sensor bullet camera

Thermal

Detector Type

Vanadium oxide uncooled focal plane detector

Effective Pixels

256x192

Pixel Pitch

12μm

Spectral Range

8μm–14μm

Thermal Sensitivity (NETD)

≤50mK

Focal Length

3.5mm; 7mm

Field of View

3.5mm: horizontal: 50.6° ; vertical: 37.8°
7mm: horizontal: 24° ; vertical: 18°

Focus Mode

3.5mm/7mm: focus free and athermalized

Aperture

F1.0

Detection Distance

3.5mm: vehicle: 389m (1276ft); human: 146m (479ft)
7mm: vehicle: 778m (2552ft); human: 292m (958ft)

Recognition Distance

3.5mm: vehicle: 97m (318ft); human: 38m (125ft)
7mm: vehicle: 194m (636ft); human: 75m (246ft)

Identification Distance

3.5mm: vehicle: 49m (161ft); human: 19m (62ft)
7mm: vehicle: 97m (318ft); human: 38m (125ft)

Digital Detail

Enhancement (DDE)

Yes

AGC

Auto; manual

Noise Reduction

2D NR; 3D NR

Color Palettes

18 color modes selectable such as Whitehot/Blackhot/Ironrow/Icefire.

Temperature

Measurement Range

Low temperature mode: -20°C (-4°F) to +150°C (302°F)

High temperature mode: 0°C (34°F) to +550°C (1022°F)

Temperature Accuracy

Max (±5°C, ±5%)

Operating temperature: -10°C (14°F) to +50°C (122°F)

Temperature Mode

Spot: 12

Line: 12

Area: 12

Support 12 rules simultaneously

Visible

Image Sensor

1/2.8 inch CMOS

Effective Pixels

1920x1080

Max. Resolution

2MP

Horizontal Definition

≥1100TVL

Min. Illumination

Color: 0.005Lux
Black & white: 0.0005Lux
IR light (on): 0Lux

AGC

Auto; manual

Noise Reduction

2D NR; 3D NR

S/N Ratio

>56dB

White Balance

Auto/indoor/outdoor/tracking/manual/sodium lamp/natural/street light

Electronic Defog

Yes

Electronic Image

Stabilization (EIS)

Yes

Electronic Shutter Speed

1/3s–1/100000s (auto or manual)

BLC

Yes

WDR

DWDR

HLC

Yes

Day/Night

Auto (ICR); color/B/W

Focus Mode

Manual

Focal Length

4mm; 8mm

Field of View

4mm: horizontal: 84°; vertical: 45°; diagonal: 99°
8mm: horizontal: 40°; vertical: 22°; diagonal: 46°

DORI Distance

Lens

Detect

Observe

Recognize

Identify

4mm

55m (180ft)

22m (72ft)

11m (36ft)

5.5m (18ft)

8mm

110m (361ft)

44m (144ft)

22m (72ft)

11m (36ft)

Close Focus Distance

0.2m

Aperture

4mm: F2.0
8mm: F1.9

IR On/Off control

Auto; manual

IR Distance

4mm: 35m (115ft)
8mm: 50m (164ft)

Audio and Video

Video Compression

H.265; H.264M; H.264H; H.264B; MJEPG

Resolution

Thermal:
(1280×960) (default value)/XVGA (1024×768)/VGA (640×480)/(256×192)
Visual:
1080P (1920×1080) (default value)/720P (1280×720)/D1 (704× 576/704×480)/CIF (352×288/352×240)

Video Frame Rate

Thermal:
50Hz:
Main stream (1280×960@25fps/1024×768@25fps/640×480@25fps/256×192@25fps), sub stream (640×480@25fps/256×192@25fps)
60Hz:
Main stream (1280×960@30fps/1024×768@30fps/640×480@25fps/256×192@25fps), sub stream (640×480@30fps/256×192@30fps)
Visual:
50Hz:
Main stream (1920×1080@25fps/1280×720@25fps/704×576@25fps), sub stream (704×576@25fps/352×288@25fps)
60Hz:
Main stream (1920×1080@30fps/1280×720@30fps/704×480@30fps), sub stream (704×480@30fps/352×240@30fps)

Audio Compression

G.711a; G.711mu; AAC; PCM

Image Encoding Format

JPEG

General Function

Two-way Talk

Yes

Network Protocol

HTTP; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP

Region of Interest (ROI)

Yes

Edge Storage

FTP; Micro SD card (256G, hot plug)

Browser

IE: IE8 and the later, and explorer with IE core
Google: 42 and the earlier
Firefox: 42 and the earlier
Safari: 10 and the earlier

User/Host

20 channels at most (the total bandwidth 64M)

Security

Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access

User Management

Support 20 users at most and users are classified as two groups--administrator group and user group.

Malfunction Detection

Network disconnection; IP addresses conflict; SD card error (status or storage space)

Smart Event

General IVS Analytics

Tripwire/intrusion

Professional and Intelligent

Fire Detection

Yes

Cold/Hot Spot Trace

Auto tracking of the hottest spot and the coldest spot in the thermal image

IVS Analytics

Tripwire/intrusion

Network

1 10M/100M Ethernet port (RJ-45)

Alarm Input

2 channels

Alarm Output

2 channels

Audio Input

1 channel

Audio Output

1 channel

RS-485

1 channel

Power

Power Supply

12V±20% DC, POE (802.3af), ePOE

Power Consumption

<5.0W (12V DC) (basic power consumption)
<12W (12V DC, without power adaptor) (maximum power consumption)

Environment

Operating Temperature

-30°C (-22°F) to +60°C (140°F)

Operating Humidity

≤95%

Self-Adaptive

Auto heating to protect the chip under the cold environment

Physical Characteristics

Protection Grade

IP67, anti-surge 6KV, anti-elctrostatic 8KV (touched by objects), anti-elctrostatic 15KV (air)

Dimensions

279.9mm (11.02")×103.8mm (4.09")×95.8mm (3.77") (lengthxwidthxheight)

Packaging Dimensions

Camera with package: 365mm (14.4"")×175mm (6.9"")×176mm (6.9"") (lengthxwidthxheight)
Deliveray box: 902mm (35.5"")×380mm (15"")×380mm (15"") (widthxlengthxheight)

Net Weight

≤1.4kg (3lb)

Gross Weight

≤1.9kg (4.2lb)

Installation Mode

Wall mount/pole mount/corner mount

Lens

Contained

Bracket

Contained

Certification

Certifications

CE (EN 60950:2000); FCC (FCC Part 15 SubpartB )
