SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR

In stock
SKU
SD50232XA-HNR
$540.00

SD50232XA-HNR

2MP 32x Starlight WizSense Network PTZ Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS

> Powerful 32x optical zoom

> Max. 50/60 fps@1080P

> Starlight technology

> Deep-learning-based auto tracking and perimeter protection

> SMD PLUS

> PoE+

> IP67 , IK10

> Face Detection

>DAHUA Logo,English firmware
>100% original products manufactured by DAHUA

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee.

in Warehouse

SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR

SD50232XA-HNR

2MP 32x Starlight WizSense Network PTZ Camera

> 1/2.8” 2Megapixel STARVIS™ CMOS

> Powerful 32x optical zoom

> Max. 50/60 fps@1080P

> Starlight technology

> Deep-learning-based auto tracking and perimeter protection

> SMD PLUS

> PoE+

> IP67 , IK10

> Face Detection

>100% original products manufactured by DAHUA

SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR SYSTEM OVERVIEW

Launched by Dahua Technology, WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on Dahua's advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions

advanced AI technologies

Featuring powerful optical zoom and accurate pan/tilt/zoom performance, this camera provides an all-in-one solution for capturing long distance video surveillance for outdoor applications. Together with infrared illumination and Starlight Technology, the camera is the perfect solution for dark, lowlight applications. The series combines a day/night mechanical IR cut filter for the highest image quality in variable lighting conditions during the day, and True WDR for applications with direct sunlight or glare.

DAHUA Smart Shop solution

SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR FUNCTIONS

Starlight+

Technology For challenging low-light applications, Dahua's Starlight Ultra-low Light Technology offers best-in-class light sensitivity, capturing color details in low light down to 0.005 lux. The camera uses a set of optical features to balance light throughout the scene, resulting in clear images in dark environments

Wide Dynamic Range

The camera achieves vivid images, even in the most intense contrast lighting conditions, using industry-leading wide dynamic range (WDR) technology. For applications with both bright and low lighting conditions that change quickly, True WDR (120 dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.

SMD PLUS

With Deep-Learning Algorithm, Dahua SMD PLUS filters the motion detection alarm triggered by non-concerned target and recognizes human and vehicle effectively, sending alarms when human and vehicles intrude

Smart H.265+

Smart H.265+ is the optimized implementation of the H.265 codec that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart H.265+ technology reduces bit rate and storage requirements by up to 70% when compared to standard H.265 video compression.

PFA Technology

PFA technology has innovatively introduced new methods of judgment to ensure the accuracy and predictability of the direction of subject distance adjustment. The result is a set of advanced focusing algorithms. PFA ensures clarity of the image throughout the process of zooming and shortens focus time. The realization of PFA technology substantially improves user experience and increases product value.

Predictive Focus Algorithm (PFA)

Predictive Focus Algorithm (PFA)

Predictive Focus Algorithm (PFA)

Perimeter Protection

Automatically filtering out false alarms caused by animals, rustling leaves, bright lights, etc. Enables system to act secondary recognition for the targets. Improving alarm accuracy. Face Detection 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, sadness, disgust, fear, surprise, calm, happiness and confusion), mask, beard; Face matting setting: face, single inch photo; Three snapshot methods: real-time snapshot, priority snapshot, quality priority.

Auto-tracking

This feature controls the pan/tilt/zoom actions of the camera to automatically track an object in motion and to keep it in the scene. The tracking action can be triggered manually or automatically by defined rules. Once a rule is triggered, the camera can zoom in and track the defined target automatically

Interoperability

The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interoperability between network video products regardless of manufacturer.

SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR PICTURE



 DAHUA DH-SD50430U-HNI


SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR DIMENSIONS




SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR INSTALLATION


SD50232XA-HNR - DAHUA DH-SD50232XA-HNR 2MP 32x Starlight WizSense Network PTZ Camera With Starlight+ Technology SD50232XA-HNR TECHNICAL SPECIFICATIONS

*******

Camera

Image Sensor

1/2.8" STARVIS™ CMOS

Pixel

2MP

Max. Resolution

1920 (H) x 1080 (V)

ROM

4 GB

RAM

1 GB

Electronic Shutter Speed

1/1 s–1/30000 s

Scanning System

Progressive

Min. Illumination

Color: 0.005 Lux@F1.35
B/W: 0.0005 Lux@F1.35

Lens

Focal Length

4.9 mm–156 mm

Max. Aperture

F1.35–F4.4

Field of View

H: 62.8°–2.2°; V: 36.7°–1.3°; D: 69.2°–2.6°

Optical Zoom

32x

Focus Control

Auto/Semi-Auto/Manual

Close Focus Distance

1 m–1.5 m (3.28 ft–4.92 ft)

Iris Control

Auto/Manual/Fixed

DORI Distance

Detect

Observe

Recognize

Identify

2152 m (7060.37 ft)

850 m (2788.71 ft)

430 m (1410.76 ft)

215 m (705.38 ft)

PTZ

Pan/Tilt Range

Pan: 0°–360° endless
Tilt: 0° to +90°, auto flip 180

Manual Control Speed

Pan: 0.1°/s–350°/s
Tilt: 0.1°/s–250°/s

Preset Speed

Pan: 500°/s
Tilt: 500°/s

Presets

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Support

Idle Motion

Preset/Tour/Pattern/Scanning

Protocol

DH-SD
Pelco-P/D (auto recognition)

General Intelligence

Event Trigger

Motion detection, video tampering, scene changing, Network disconnection, IP address conflict, illegal access, and storage anomaly.

IVS

Object Abandoned/Missing

Artificial Intelligence

Smart Capture

Support human, motor vehicle and non-motor vehicle image capture.

Perimeter Protection

Tripwire and intrusion. Support alarm triggering by target types (human and vehicle). Support filtering false alarms caused by animals, rustling leaves, bright lights, etc.

Face Detection

Support

Auto Tracking

Support

SMD PLUS

Support

Video

Compression

H.265; H.264B; H.264M; H.264H; MJPEG (Sub Stream); H.265+; H.264+

Streaming Capability

3 streams

Resolution

1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); CIF (352×288)

Frame Rate

Main stream: 1080P/1.3M/720P (1–50/60 fps)

Sub stream 1: D1/CIF (1–25/30 fps)
Sub stream 2: 720P (1–25/30 fps)

Bit Rate Control

Variable/Constant

Bit Rate

H.264: 3 Kbps–20480 Kbps
H.265: 3 Kbps–20480 Kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Support

WDR

120 dB

HLC

Support

White Balance

Auto/Indoor/Outdoor/Tracking/Manual/Sodium lamp/Natural light/Street lamp

Gain Control

Auto/Manual

Noise Reduction

2D/3D

Motion Detection

Support

Region of Interest (RoI)

Support

Image Stabilization

Electronic

Defog

Electronic

Digital Zoom

16x

Flip

180°

Privacy Masking

Up to 24 areas, and up to 8 areas in the same view

S/N Ratio

≥ 55 dB

Audio

Compression

G.711a; G.711Mu; G.726; AAC; MPEG2-Layer2; G722.1; G729; G723

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

IPv4; IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMPv1/v2c/v3 (MIB-2); DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ARP; RTCP

Interoperability

ONVIF Profile S&G&T; CGI

Streaming Method

Unicast/Multicast

User/Host

20 (total bandwidth 64M)

Storage

FTP; Micro SD card (256G); NAS

Browser

IE7 and later versions
Chrome 42 and earlier versions
Firefox 52 and earlier versions
Safari

Management Software

Smart PSS; DSS; DMSS; Easy4ip; IVSS

Mobile Phone

IOS, Android

Certification

Certifications

CE: EN55032/EN55024/EN50130-4
FCC: Part15 subpartB, ANSI C63.4-2014

UL: UL62368-1+CAN/CSA C22.2,No. 62368-1

Port

Audio Input

1

Audio Output

1 (LINE OUT; bare wire)

Two-way Audio

Support

Alarm I/O

2/1

Power

Power Supply

DC24V/2.5A

PoE+ (802.3at)

Power Consumption

Basic: 10W
Max: 16W

Environment

Operating Temperature

–40°C to +60°C (–40°F to +140°F)

Operating Humidity

≤ 95%

Protection

IP67; IK10; 6000V lightning proof; surge protection; voltage transient protection

Structure

Dimensions

Φ186 mm x 253 mm (Φ7.32" x 9.96")

Net Weight

2.5 kg (5.51 lb)

Gross Weight:

4.5 kg (9.92 lb)



*******
