IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S

In stock
SKU
IPC-HFW1531S-1
Rating:
100% of 100
$85.99

IPC-HFW1531S

5MP WDR IR Mini-Bullet Camera

> 1/2.7” 5Megapixel progressive CMOS
> H.265 & H.264 dual-stream encoding
> 15fps@5M(2592×1944) &25/30fps@3M(2304×1296)
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.8 mm fixed lens (3.6 mm optional)
> Max IR LEDs Length 30m
> IP67, PoE
>,English firmware
>100% original products manufactured by DAHUA

IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S

IPC-HFW1531S

5MP WDR IR Mini-Bullet Camera

> 1/2.7” 5Megapixel progressive CMOS
> H.265 & H.264 dual-stream encoding
> 15fps@5M(2592×1944) &25/30fps@3M(2304×1296)
> WDR(120dB), Day/Night(ICR), 3DNR, AWB, AGC, BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.8 mm fixed lens (3.6 mm optional)
> Max IR LEDs Length 30m
> IP67, PoE
>,English firmware
>100% original products manufactured by DAHUA

IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S System Overview



The IR Megapixel Vari-focal camera delivers 2MP resolution with a 2.7~13.5mm varifocal lens.The camera's elegant blend of aesthetics combined with a range of easy mounting solutions provides an excellent choice for a variety of small to mid-size applications at an affordable price.

DAHUA Smart Shop solution

IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S Functions

Smart (H.265+ & H.264+)

Adopting advanced algorithm of auto stream control according to the environment, Dahua smart encoding technology realizes the higher efficiency than (H.265 & H.264 ), providing high-quality video, and reducing the cost of storage and transmission.

Smart IR Technology

With IR illumination, detailed images can be captured in low light or total darkness. The camera's Smart IR technology adjusts the intensity of camera's infrared LEDs to compensate the distance of an object. Smart IR technology prevents IR LEDs from whitening out images as they come closer to the camera. The camera's integrated infrared illumination provides high performance in extreme low-light environments up to 30m (98ft).

Intelligent Video Analysis (IVS)

With advanced video algorithm, Dahua camera supports intelligent detection, such as tripwire and intrusion and so on.

Protection (IP67, wide voltage)

IP67: The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

Environmental

cameras operate in extreme temperature environments, rated for use in temperatures from -30° C to +60° C (-22° F to +140° F) with 95% humidity.

Image Flip

Capturing unnecessary data such as surrounding hallway walls can increase storage requirements without any added value. The image flip feature allows the camera's image to be rotated in 90° increments for better video optimization.

Interoperability

The camera conforms to the ONVIF (Open Network Video Interface Forum) specifications, ensuring interoperability between network video products regardless of manufacturer.

IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S Picture



IPC-HFW1531S


IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S  Dimensions




IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S  Installation


IPC-HFW1531S - DAHUA DH-IPC-HFW1531S 5MP WDR IR Mini-Bullet Camera With Smart IR Technology Intelligent Video Analysis (IVS) Wide Dynamic Range (WDR) IPC-HFW1531S Technical Specifications

****

Camera

Image Sensor

1/2.7” 5Megapixel progresive CMOS

Effective Pixels

2592(H)x1944(V)

RAM/ROM

512MB/32MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.03Lux/F2.0( Color,1/3s,30IRE)

0.3Lux/2.0( Color,1/30s,30IRE)

0Lux/F2.0(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 30m(98ft)

IR On/Off Control

Auto/ Manual

IR LEDs

18

Lens

Lens Type

Fixed

Mount Type

Board-in

Focal Length

2.8 mm (3.6 mm optional)

Max. Aperture

F2.0/F2.0

Angle of View

H:96°/78°, V:70°/58°

Focus Control

Fixed

Close Focus Distance

N/A

DORI Distance

Lens

Detect

Observe

Recognize

Identify

2.8 mm

63m(207ft)

25m(82ft)

13m(43ft)

6m(20ft)

3.6 mm

80m(262ft)

32m(105ft)

16m(52ft)

8m(26ft)

PTZ

Pan/Tilt Range

Pan:0° ~360° ;Tilt:0° ~90° ;Rotation:0° ~360°

Intelligence

Event Trigger

Motion detection, Video tampering, Scene changing, Network disconnection, Ip address conflict, Illegal access, Storage anomaly

IVS

Tripwire, Intrusion

Video

Compression

H.265/H.264H/MJPEG(Sub Stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

2 Streams

Resolution

5M(2592×1944)/4M(2688x1520)/3M(2304×1296/2048x1536)/1080P(1920×1080)/720P(1280×720)/

D1(704×576/704×480)/VGA(640×480)/CIF(352×288/352×240)

Frame Rate

Main Stream: 5M(1 ~ 15fps)/3M (1 ~ 25/30fps)

Sub Stream: D1(1 ~ 25/30fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.265: 12K ~ 8448Kbps

H.264: 32K ~ 10240Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

N/A

Smart IR

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

N/A

Network

Ethernet

RJ-45 (10/100Base-T)

Protocol

HTTP;HTTPS;TCP;ARP;RTSP;RTP;RTCP;UDP;SMTP;

FTP;DHCP;DNS;DDNS;PPPoE;IPV4/V6;QoS;UPnP;

NTP;Bonjour;IEEE 802.1X;Multicast;ICMP;IGMP;TLS

Interoperability

ONVIF Profile S&G, API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users / 20 Users

Edge Storage

NAS

Local PC for instant recording

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

N/A

Audio Interface

N/A

RS485

N/A

Alarm

N/A

Electrical

Power Supply

DC12V, PoE(IEEE 802.3af)(Class 0)

Power Consumption

< 6W

Environmental

Operating Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Stroage Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

N/A

Construction

Casing

Metal+Plastic

Dimensions

Φ70mm×164.7mm(2.76''x6.49'')

Net Weight

0.38Kg(0.84lb)

Gross Weight

0.44Kg(0.97lb)

****

**

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

***

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Fixed
Day/Night Day/Night
Factor Bullet
Max Resolution 5 MP
