HIKVISION DS-2CD2185FWD-I 4K Fixed Dome Network Camera

In stock
SKU
BVDS-2CD2185FWD-I
$159.00

DS-2CD2183G0-I

High quality imaging with 8 MP resolution

Efficient H.265+ compression technology

Clear imaging against strong back light due to 120 dB true WDR technology

-S: audio and alarm interface available

Water and dust resistant (IP67) and vandal proof (IK10)

Robust structure design with full metal materials



100% original products

HIKVISION DS-2CD2183G0-I 4K Outdoor WDR Fixed Dome Network Camera

DS-2CD2183G0-I

4K Outdoor WDR Fixed Dome Network Camera

High quality imaging with 8 MP resolution

Efficient H.265+ compression technology

Clear imaging against strong back light due to 120 dB true WDR technology

-S: audio and alarm interface available

Water and dust resistant (IP67) and vandal proof (IK10)

Robust structure design with full metal materials



100% original products

HIKVISION DS-2CD2183G0-I 4K Outdoor WDR Fixed Dome Network Camera Picture



DS-2CD2125FWD-I


HIKVISION DS-2CD2183G0-I 4K Outdoor WDR Fixed Dome Network Camera  Dimensions




HIKVISION DS-2CD2183G0-I 4K Outdoor WDR Fixed Dome Network Camera  Installation


HIKVISION DS-2CD2183G0-I 4K Outdoor WDR Fixed Dome Network Camera Technical Specifications

*******

*

  • Camera
  • Image Sensor1/2.5" Progressive Scan CMOS
  • Min. IlluminationColor: 0.01 lux @(F1.2, AGC ON), 0.028 lux @(F2.0, AGC ON), 0 lux with IR
  • Shutter Speed1/3 s to 1/100,000 s
  • Slow ShutterYes
  • Wide Dynamic Range120dB
  • Day & NightIR Cut Filter
  • Angle AdjustmentPan: 0° to 355°, tilt: 0° to 75°, rotate: 0° to 355°
  • Lens
  • FocusFixed
  • Lens Type2.8/4/6/8 mm
  • FOV2.8 mm, horizontal FOV: 102°, vertical FOV: 53°, diagonal FOV: 124°,4 mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 95°,6 mm, horizontal FOV: 50°, vertical FOV: 28°, diagonal FOV: 59°,8 mm, horizontal FOV: 40°, vertical FOV: 25°, diagonal FOV: 53°
  • ApertureF2.0
  • Lens MountM12
  • Aperture TypeFixed
  • Illuminator
  • IR RangeUp to 30 m
  • Wavelength850nm
  • Video
  • Max. Resolution3840 × 2160
  • Main Stream50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720),60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
  • Sub Stream50Hz: 25fps (640 × 480, 640 × 360, 320 × 240),60Hz: 30fps (640 × 480, 640 × 360, 320 × 240)
  • Third Stream50Hz: 25fps (1280 × 720, 640 × 360, 352 × 288),60Hz: 30fps (1280 × 720, 640 × 360, 352 × 240)
  • Video CompressionMain stream: H.265/H.264,Sub-stream: H.265/H.264/MJPEG,Third stream: H.265/H.264
  • Video Bit Rate32 Kbps to 16 Mbps
  • H.264 TypeMain Profile/High Profile
  • H.265 TypeMain Profile
  • H.264+Main stream supports
  • H.265+Main stream supports
  • Scalable Video Coding (SVC)H.264 and H.265 encoding support
  • Audio
  • Environment Noise FilteringYes
  • Audio Sampling Rate8 kHz/16 kHz/32 kHz/44.1 kHz/48 kHz
  • Audio CompressionG.711/G.722.1/G.726/MP2L2/PCM
  • Audio Bit Rate64Kbps(G.711)/16Kbps(G.722.1)/16Kbps(G.726)/32-192Kbps(MP2L2)
  • Network
  • Simultaneous Live ViewUp to 6 channels
  • APIONVIF (PROFILE S, PROFILE G), ISAPI
  • ProtocolsTCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour
  • User/HostUp to 32 users,3 levels: Administrator, Operator and User
  • Network StorageSupport Micro SD/SDHC/SDXC card (128G), local storage and NAS (NFS,SMB/CIFS), ANR
  • ClientiVMS-4200, Hik-Connect, iVMS-5200, iVMS-4500
  • Web BrowserPlug-in required live view:,IE8+, Chrome 41.0-44, Firefox 30.0-51, Safari 8.0-11,Plug-in free live view:,Chrome 45.0+, Firefox 52.0+
  • Alarm TriggerMotion detection, video tampering, network disconnected, IP address conflict, illegal login, HDD full, HDD error
  • Image
  • Day/Night SwitchDay/Night/Auto/Schedule/Triggered by Alarm In (-S)
  • Target CroppingNo
  • DNR3D DNR
  • Image EnhancementBLC/3D DNR /HLC
  • Image SettingsSaturation, brightness, contrast, sharpness, AGC, and white balance are adjustable by client software or web browser
  • Interface
  • Audio1 input (line in/mic in), 1 output (line out), terminal block, mono sound
  • Alarm1 input;1 output (max. 12 VDC, 30 mA), terminal block
  • Video OutputNo
  • On-Board StorageBuilt-in microSD/SDHC/SDXC slot, up to 128 GB
  • Hardware ResetYes
  • Communication Interface1 RJ45 10M/100M self-adaptive Ethernet port
  • Event
  • Face DetectionYes
  • General
  • General FunctionOne-key reset, anti-flicker, three streams, heartbeat, mirror, password protection, privacy mask, watermark, IP address filter
  • Startup And Operating Conditions-30 °C to +60 °C (-22 °F to +140 °F), humidity 95% or less (non-condensing)
  • Power Supply12 VDC ± 25%, Φ 5.5 mm ,PoE(802.3af, class 3)
  • Power Consumption And CurrentDC: 12 V, 0.6 A, max. 7.5 W,PoE: (802.3af, 36 V to 57 V), 0.3 A to 0.2 A, max. 9 W
  • Camera DimensionCamera: Φ 111 mm × 82.4 mm (Φ 4.4" × 3.2"),Package: 134 × 134 × 108 mm (5.3" × 5.3" × 4.3")
  • Camera WeightCamera: approx. 500 g (1.1 lb.)
  • Approval
  • ProtectionIK10, IP67



*

**********

*
