IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognitionCamera IPC-HFW8242E-Z4FR-IRA-LED

In stock
SKU
IPC-HFW8242E-Z4FR-IRA-LED
$1,095.70



IPC-HFW8242E-Z4FR-IRA-LED



2MP Starlight Bullet Network Camera

> 1/1.8” 2Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@1080P(1920×1080)
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Micro SD memory, PoE+
> Max. LED Length 10m
> Support face capture, face attributes, face recognition


>without Logo,English firmware
>100% original products manufactured by DAHUA




The delivery time is 25 working days .

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognition Camera IPC-HFW8242E-Z4FR-IRA-LED

IPC-HFW8242E-Z4FR-IRA-LED

2MP Starlight Bullet Network Camera

> 1/1.8” 2Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@1080P(1920×1080)
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Micro SD memory, PoE+
> Max. LED Length 10m
> Support face capture, face attributes, face recognition

>,English firmware
>100% original products manufactured by DAHUA




IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognition Camera IPC-HFW8242E-Z4FR-IRA-LED  System Overview

Face recognition AI network camera is designed to focus on the recognition of frontal human faces, it adopts high performance smart chip with deep learning technology, which can provide high precision face image snapshot and comparison. This product supports real-time face detection, face attributes analysis, face images comparison and face image database management.

IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognition Camera IPC-HFW8242E-Z4FR-IRA-LED  Functions

Face Capture
Face capture is a software application that automatically captures faces from within a digital image or a video frame from a video source. Dahua cameras use advanced deep learning algorithms and are trained by a large number of face data sources, enabling the camera to locate faces quickly and accurately from the video source and capture facial images.


Face Attributes
Through the use of deep learning algorithms to analyze facial images, Dahua cameras can extract six facial attributes from each frame, including gender, age, expression (happy, calm, surprised, sad, and angry), glasses, masks, and mustaches. Customers can acquire data of interest via face attributes statistics.


Metadata
Metadata is feature attribute information extracted from a target object which can be used for data retrieval. Dahua face recognition camera can extract six facial attributes and output the metadata for analysis.

Once facial features are extracted from captured faces, they are stored in a database where they can be easily searched and compared against other images. Once a successful match is found, the system outputs the result. The Dahua Face Recognition camera supports a built-in database that stores up to 10,000 facial images, helping the camera achieve real-time face capture and comparison.


Starlight Technology
Featuring Dahua’s Starlight Technology, this camera is ideal for applications with challenging lighting conditions. Its low-light performance delivers usable video with minimal ambient light. Even in extreme low-light conditions, Starlight Technology is capable of delivering color images in near complete darkness.

starlight
Wide dynamic range (WDR)
Embeded with industry leading wide dynamic range (WDR) technology, vivid picutures are achieved even in the most intense contrast lighting conditions. For applications with both bright and low lighting conditions that change quickly, True WDR (120dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.


Smart Codec (H.265+ & H.264+)
Smart Codec is the optimized implementation of standard video compression (H.265 & H.264) that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart Codec technology reduces bit rate and storage requirements by up to 70% when compared to the standard video compression.


>,English firmware
>
100% original products manufactured by DAHUA - See more at: http://www.cctv-mall.com/dahua-ipc-hfw81200e-z-dahua-ipc-hfw81200e-z-4k-ultra-hd-12-megapixel-ultra-hd-network-bullet-camera-with-4-1mm-16-4mm-motorized-lens-and-poe-ip67#sthash.PYy4AcYd.dpuf

IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognitionCamera IPC-HFW8242E-Z4FR-IRA-LED Picture

DH-IPC-HFW83A1EN-Z5 3MP Starlight IR Vari-focal Bullet Network Camera Picture



DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED

 IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognitionCamera IPC-HFW8242E-Z4FR-IRA-LED Dimension

DH-IPC-HFW83A1EN-Z5 3MP Starlight IR Vari-focal Bullet Network Camera Dimension

>,English firmware
>
100% original products manufactured by DAHUA - See more at: http://www.cctv-mall.com/dahua-ipc-hfw81200e-z-dahua-ipc-hfw81200e-z-4k-ultra-hd-12-megapixel-ultra-hd-network-bullet-camera-with-4-1mm-16-4mm-motorized-lens-and-poe-ip67#sthash.PYy4AcYd.dpufIPC-HFW8331E-Z  DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera ApplicationDAHUA IPC-HFW8331E-Z - DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera

IPC-HFW8242E-Z4FD-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FD-IRA-LED 2MP Starlight Bullet Network Camera IPC-HFW8242E-Z4FD-IRA-LED without Logo Dimension

IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognitionCamera IPC-HFW8242E-Z4FR-IRA-LED Installation

DAHUA DH-IPC-HFW8242E-Z4FD-IRA-LED

IPC-HFW8242E-Z20FR-IRA-LED

IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognitionCamera IPC-HFW8242E-Z4FR-IRA-LED Specifications

DH-IPC-HFW83A1EN-Z 3MP Starlight IR Vari-focal Bullet Network Camera Specifications

Technical Specifications

 *******

Camera

Image Sensor

1/1.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

2048MB/4096MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.002Lux/F1.53( Color,1/3s,30IRE)

0.01Lux/F1.53( Color,1/30s,30IRE)

0Lux/F1.53(LED on)

S/N Ratio

More than 50dB

LED Distance

Distance up to 10m(33ft)

LED On/Off Control

Auto/Manual

LEDs

6

Lens

Lens Type

Motorized

Mount Type

Board-in

Focal Length

8~32mm motorized

Max. Aperture

F1.53

Angle of View

H: 40°~12.9° V:22°~7.2°

Optical Zoom

4x

Focus Control

Motorized

Close Focus Distance

3m(9.84ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

106m(348ft)

42m(138ft)

21m(69ft)

10m(32ft)

T

320m(1050ft)

128m(420ft)

64m(210ft)

32m(105ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚

Artificial Intelligence

Face Capture

Support face image capture

Face Attributes

Support 6 kinds of face attributes extraction: Age, Gender, Expression(Jolly, Calm, Surprise, Sad, Rage), Glasses, Mouth Mask, Moustache & Beard

Face Recognition

Support face images matching, support up to 10000 face images and 5 image libraries management;

General Intelligence

Event Trigger

Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly

General Intelligence

Tripwire, Intrusion, Object Abandoned/Missing, People Counting, Heat Map

Video

Compression

H.265/H.264/H.264B/H.264H/MJPEG(sub stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ VGA(640x480)

Frame Rate

Main Stream: 1080P(1~50/60fps)

Sub Stream: D1 (1 ~ 50/60fps)

Third Stream: 1080P(1~50/60fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 24~ 10240Kbps

H.265: 14~ 6144Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)/ SSA

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

Support

Smart IR

N/A

Defog

Support

Digital Zoom

N/A

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/ G.711Mu/ AAC/ G.726

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;

FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;

NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S

NMP;TLS

Interoperability

ONVIF Profile S&G, API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Micro SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

1 port(BNC,1Vp-p,75Ω )

Audio Interface

1/1 channel In/Out

RS485

1 port

Alarm

3 channel In: 5mA 5VDC

2 channel Out: 1A 30VDC / 0.5A 50VAC

Power Out

165mA 12VDC

Electrical

Power Supply

DC12V, PoE+(802.3at)(Class 4)

Power Consumption

DC12V:5W 20W(IR on)

PoE:5W 21W(IR on)

Environmental

Operating Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Storage Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

457mm*124.3mm*108mm(18×4.89×4.25)

Net Weight

1.87Kg (4.12lb)

Gross Weight

3.43Kg (7.56lb)

*********

********

*

**
