DS-7608NI-I2/8P - Hikvision DS-7608NI-I2/8P 8-ch 1U 8 PoE 4K NVR TECHNICAL SPECIFICATIONS

*********

Video And Audio

IP Video Input8-ch

HDMI Output4K (3840 × 2160)/60Hz, 4K (3840 × 2160)/30Hz, 2K (2560 × 1440)/60Hz, 1920 × 1080p/60Hz, 1600 × 1200/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

VGA Output1920 × 1080p/60Hz, 1280 × 1024/60Hz, 1280 × 720/60Hz, 1024 × 768/60Hz

CVBS Output1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480

Incoming Bandwidth80 Mbps 256 Mbps

Audio Output1-ch, RCA (Linear, 1 KΩ)

Two-Way Audio1-ch, RCA (2.0 Vp-p, 1 k Ω)

Decoding

Decoding FormatH.265+,H.265,H.264+,H.264

Decoding Capability16-ch@1080p

Synchronous Playback8-ch

Recording Resolution12 MP/8 MP/6 MP/5 MP/4 MP/3MP/1080p/UXGA/720p /VGA/4CIF /DCIF/2CIF/CIF/QCIF

Network

Network ProtocolTCP/IP, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, SMTP, NFS, iSCSI, UPnP™, HTTPS

Remote Connection32

Network Interface1 RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

Interface8-ch

Power≤ 120 W ≤ 180 W

StandardIEEE 802.3 af/at

RAID

RAID TypeNo

Auxiliary Interface

SATA2

CapacityUp to 8TB capacity for each HDD

USB InterfaceFront panel: 1 × USB 2.0; Rear panel: 1 × USB 3.0

Alarm In/Out4/1

General

Power Supply100 to 240 VAC, 50 to 60 Hz

Consumption≤15 W (without enabling PoE)

Working Temperature-10 °C to 55 °C (14 °F to 131 °F)

Working Humidity10 to 90 %

Dimension (W × D × H)385 × 315× 52 mm (15.2" × 12.4" × 2.0")

Weight≤ 3 kg (6.6 lb)

********

*
