IPC-HFW8331E-Z- DAHUA DH-IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera with 2.7mm ~13.5mm motorized lens Micro SD memory,IP67,IK10,PoE+ IPC-HFW8331E-Z

In stock
SKU
IPC-HFW8331E-Z
$303.00

IPC-HFW8331E-Z

>1/2.8” 3Megapixel progressive scan CMOS
>Support H.265/H.264/MJPEG codec
>Smart triple streams supported
>Max 25/30fps@3MP(2048x1536)
>Ultra WDR up to 140dB
>Ultra 3D DNR
>Ultra Defog, ROI, EIS
>Smart detection
>Intelligent Function
>2.8 ~12mm varifocal motorized lens
>Max. IR LEDs length 50m
>Micro SD memory, IP67, PoE
>without Logo,English firmware
>100% original products manufactured by DAHUA


The delivery time is 25 working days if no stock.

IPC-HFW8331E-Z- DAHUA DH-IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera with 2.7mm ~13.5mm motorized lens Micro SD memory,IP67,IK10,PoE+ IPC-HFW8331E-Z without Logo

DH-IPC-HFW83A1EN-Z 3MP Starlight IR Vari-focal Bullet Network Camera

IPC-HFW8331E-Z

3MP WDR IR Bullet Network Camera

> 1/2.8” 3Megapixel progressive scan STARVIS™ CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@3M(2048×1536)
> WDR(140dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 2.7mm ~13.5mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory,IP67,IK10,PoE+

>without Logo,English firmware
>100% original products manufactured by DAHUA

IPC-HFW8331E-Z- DAHUA DH-IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera with 2.7mm ~13.5mm motorized lens Micro SD memory,IP67,IK10,PoE+ IPC-HFW8331E-Z without Logo System Overview

Ultra series product adopts high performance DSP and Sony advanced image sensor technology, which can provide excellent image effects for users such as UHD resolution, starlight and super WDR etc. The series utilizes  advanced software algorithm, which is able to support people counting and heat map, bringing extra business analysis value for customers; IP67, IK10 and heater compliance enables the product to be applied in a more harsh environment.

smart retail DAHUA

IPC-HFW8331E-Z- DAHUA DH-IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera with 2.7mm ~13.5mm motorized lens Micro SD memory,IP67,IK10,PoE+ IPC-HFW8331E-Z without Logo Functions

starlightStarlight Technology

Featuring  Starlight Technology, this camera is ideal for applications with challenging lighting conditions. Its low-light performance delivers usable video with minimal ambient light. Even in extreme low-light conditions, Starlight Technology is capable of delivering color images in near complete darkness (0.005 lux).

Ultra WDR Standard WDR/HDR camera can provide 120dB dynamic range,However, for some scenes with wider contrast range, 120dB is slightly insufficient. By adopting the latest technology, Dahua Cameras can provide an amazing dynamic range up to140dB.

Intelligent Video System (IVS)

camera has a built-in video analysis based on intelligent algorithms and can achieve the following:Tripwire,Intrusion,Abandoned/ Missing can timely, quickly and accurately respond to monitoring events in specific area. It enhances monitoring efficiency. At the same time, the camera can support face detection,it can quickly capture a face and upload the image to the server. In addition the camera also supports intelligent tamper detection,through dramatic changes in the scene it will send out warning information to ensure effective monitoring.

Business intelligent analysis (People counting, Heatmap)

Camera also supports more advanced intelligent features such as people counting and heat map besides basic IVS functions. These two functions can be applied to business intelligence and bring extra values to customers. It is available to acquire daily, weekly, monthly and yearly people flow via people counting and output data report. Heat map can be based on a moving object in time of space movement for analysis, find the most active area and output the report, which is to provide valuable data support for commercial applications.

Smart Scene Adaptive (SSA)

Smart Scene Adaptive (SSA) is a  self-developed intelligent image technology, the camera automatically evaluates the change in scene, in particular strong lights.In a strong backlight environment, it will automatically regulate exposure parameters to get better image quality. This can effectively address the impact of traffic lights, providing excellent video quality.

HEVC (H.265)

H.265 ITU-T VCEG is a new video coding standard. H.265 Following standard developed around the existing video coding standard H.264 , some retain the original technology , while some of the relevant technology to improve the new technology uses advanced technology to improve the relationship between the code stream , encoding quality , and the delay between algorithm complexity , optimize settings specific contents include : Improve compression efficiency , improve the robustness and error recovery capabilities, real-time to reduce the delay, reduce channel acquisition time and a random access delay , reduce complexity , etc

Environmental

With a temperature range of -40 °C to +60 °C (-40 °F to +140 °F), the camera is designed for extreme temperature environments. The camera complies to an IK10 impact rating making it capable of withstanding the equivalent of 55 kg (120 lbs) of force. Subjected and certified to rigorous dust and water immersion tests, the IP67 rating makes it suitable for demanding outdoor applications.


>without Logo,English firmware
>
100% original products manufactured by DAHUA - See more at: http://www.cctv-mall.com/dahua-ipc-hfw81200e-z-dahua-ipc-hfw81200e-z-4k-ultra-hd-12-megapixel-ultra-hd-network-bullet-camera-with-4-1mm-16-4mm-motorized-lens-and-poe-ip67#sthash.PYy4AcYd.dpuf

IPC-HFW8331E-Z - DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera Picture

DH-IPC-HFW83A1EN-Z 3MP Starlight IR Vari-focal Bullet Network Camera Picture

 IPC-HFW8331E-Z

 IPC-HFW8331E-Z - DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera Dimension

 IPC-HFW5241E-ZHE

>without Logo,English firmware
>
100% original products manufactured by DAHUA - See more at: http://www.cctv-mall.com/dahua-ipc-hfw81200e-z-dahua-ipc-hfw81200e-z-4k-ultra-hd-12-megapixel-ultra-hd-network-bullet-camera-with-4-1mm-16-4mm-motorized-lens-and-poe-ip67#sthash.PYy4AcYd.dpufIPC-HFW8331E-Z  DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera ApplicationDAHUA IPC-HFW8331E-Z - DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera

 IPC-HFW8331E-Z - DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network Motorized IR Camera Installation

DH-IPC-HFW5241E-ZHE without logo Installation

IPC-HFW5241E-Z12E without logo Installation

IPC-HFW8331E-Z - DAHUA IPC-HFW8331E-Z 3Megapixel Full HD WDR Smart Network  Motorized IR Camera Specifications

DH-IPC-HFW83A1EN-Z 3MP Starlight IR Vari-focal Bullet Network Camera Specifications

Technical Specifications

 *************

Camera

Image Sensor

1/2.8”3Megapixel progressive scan CMOS

Effective Pixels

2048(H)x1536(V)

RAM/ROM

1024MB/128MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.005Lux/F1.4 (Color,1/3s,30IRE)

0.03Lux/F1.4 (Color,1/30s,30IRE)

0Lux/F1.4(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 50m(164ft)

IR On/Off Control

Auto/ Manual

IR LEDs

4

Lens

Lens Type

Motorized /Auto Iris(HALL)

Mount Type

Board-in

Focal Length

2.7~13.5mm motorized

Max. Aperture

F1.4

Angle of View

H: 101°~31°, V:54°~17°

Optical Zoom

5x

Focus Control

Motorized

Close Focus Distance

0.3m(0.98ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

54m(177ft)

22m(72ft)

11m(36ft)

5m(16ft)

T

166m(545ft)

66m(217ft)

33m(108ft)

17m(56ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚

Intelligence

IVS

Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions

Face Detection, People Counting, Heat Map

Video

Compression

H.265+/H.265/H.264+/H.264

Streaming Capability

3 Streams

Resolution

3M(2048x1536)/ 1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ VGA(640x480)/ CIF(352×288/342x240)

Frame Rate

Main Stream: 3M(1~50/60fps)

Sub Stream: D1 (1 ~ 50/60fps)

Third Stream: 1080P(1~50/60fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 24~ 10240Kbps

H.265: 14~ 9216Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(140dB)/ SSA

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detetion

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

Support

Smart IR

Support

Defog

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/G.711Mu/AAC/ G.726

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;

DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;

Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP

Interoperability

ONVIF, PSIA, CGI

Streaming Method

Unicast / Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Mirco SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, Easy4ip

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

1 Port(For adjustment only)

Audio Interface

1/1 channel In/Out

RS485

N/A

Alarm

2 channel In: 5mA 5VDC

1 channel Out: 1A 30VDC / 0.5A 50VAC

Electrical

Power Supply

DC12V, PoE+ (802.3at)(Class 4)

Power Consumption

<13W

Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Strorage Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

273.2mm×95.0mm×96.4mm (10.76×3.74×3.79)

Net Weight

1.12Kg (2.47lb)

Gross Weight

1.52Kg (3.35lb)

******

********

*

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR
Worldwide shipping DAHUA camera
best price of DAHUA camera

***

***********

Save

Save

Save

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Motorized Zoom, Vari-Focal
Day/Night D/N IR, Day/Night, Low light
Factor Bullet
Max Resolution 4K
