IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z

Out of stock
SKU
IPC-HFW8232E-Z
$325.00



IPC-HFW8232E-Z



2MP Starlight IR Bullet Network Camera

> 1/1.9” 2Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@1080P(1920×1080)
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 4.1mm ~16.4mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory,IP67,IK10,Po



Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo



IPC-HFW8232E-Z

2MP Starlight IR Bullet Network Camera

> 1/1.9” 2Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@1080P(1920×1080)
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> 4.1mm ~16.4mm motorized lens
> Max. IR LEDs Length 50m
> Micro SD memory,IP67,IK10,PoE

> without Logo,English firmware
>100% original products manufactured by DAHUA



IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo System Overview

Ultra series product adopts high performance DSP and Sony advanced image sensor technology, which can provide excellent image effects for users such as UHD resolution, starlight and super WDR etc. The series utilizes Dahua advanced software algorithm, which is able to support people counting and heat map, bringing extra business analysis value for customers; IP67, IK10 and heater compliance enables the product to be applied in a more harsh environment.

DAHUA Smart Shop solution

IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo Functions

Starlight Technology

Featuring Dahua’s Starlight Technology, this camera is ideal for applications with challenging lighting conditions. Its low-light performance delivers usable video with minimal ambient light. Even in extreme low-light conditions, Starlight Technology is capable of delivering color images in near complete darkness (0.005 lux).

Wide dynamic range (WDR)

Embeded with industry leading wide dynamic range (WDR) technology, vivid picutures are achieved even in the most intense contrast lighting conditions. For applications with both bright and low lighting conditions that change quickly, True WDR (120dB) optimizes both the bright and dark areas of a scene at the same time to provide usable video.

Intelligent Video System (IVS)

camera has a built-in video analysis based on intelligent algorithms and can achieve the following:Tripwire,Intrusion,Abandoned/ Missing can timely, quickly and accurately respond to monitoring events in specific area. It enhances monitoring efficiency. At the same time, the camera can support face detection,it can quickly capture a face and upload the image to the server. In addition the camera also supports intelligent tamper detection,through dramatic changes in the scene it will send out warning information to ensure effective monitoring.

Business intelligent analysis (People counting, Heatmap)

Camera also supports more advanced intelligent features such as people counting and heat map besides basic IVS functions. These two functions can be applied to business intelligence and bring extra values to customers. It is available to acquire daily, weekly, monthly and yearly people flow via people counting and output data report. Heat map can be based on a moving object in time of space movement for analysis, find the most active area and output the report, which is to provide valuable data support for commercial applications.

Smart Scene Adaptive (SSA)

Smart Scene Adaptive (SSA) is a  self-developed intelligent image technology, the camera automatically evaluates the change in scene, in particular strong lights.In a strong backlight environment, it will automatically regulate exposure parameters to get better image quality. This can effectively address the impact of traffic lights, providing excellent video quality.

HEVC (H.265)

H.265 ITU-T VCEG is a new video coding standard. H.265 Following standard developed around the existing video coding standard H.264 , some retain the original technology , while some of the relevant technology to improve the new technology uses advanced technology to improve the relationship between the code stream , encoding quality , and the delay between algorithm complexity , optimize settings specific contents include : Improve compression efficiency , improve the robustness and error recovery capabilities, real-time to reduce the delay, reduce channel acquisition time and a random access delay , reduce complexity , etc

Environmental

With a temperature range of -40 °C to +60 °C (-40 °F to +140 °F), the camera is designed for extreme temperature environments. The camera complies to an IK10 impact rating making it capable of withstanding the equivalent of 55 kg (120 lbs) of force. Subjected and certified to rigorous dust and water immersion tests, the IP67 rating makes it suitable for demanding outdoor applications.

>without Logo,English firmware
>100% original products manufactured by DAHUA - See more at: http://www.cctv-mall.com/dahua-ipc-hfw8331e-z-dahua-ipc-hfw8331e-z-3megapixel-full-hd-wdr-smart-network-motorized-ir-camera#sthash.H7MYKr3c.dpuf

IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo Picture

DAHUA HFW8231E-Z

IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo Dimension

IPC-HFW5241E-ZHE

IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo Application


DAHUA DH-IPC-HFW8232E-ZIPC-HFW8232E-Z


IPC-HFW8232E-Z - DAHUA DH-IPC-HFW8232E-Z 2MP Starlight IR Bullet Network Camera with 4.1mm ~16.4mm motorized lens Intelligent Video System Business intelligent analysis (People counting, Heatmap) IPC-HFW8232E-Z without logo Technical Specifications

Technical Specification

*****

 Camera

Image Sensor

1/1.9” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

1024MB/128MB

Scanning System

Progressive

Minimum Illumination

0.002Lux/F1.53( Color), 0Lux/F1.53(IR on)

S/N Ratio

More than 50dB

IR Distance

Distance up to 50m(164ft)

IR On/Off Control

Auto/ Manual

IR LEDs

4

Lens

Lens Type

Motorized /Auto Iris(HALL)

Mount Type

Board-in

Focal Length

4.1~16.4mm motorized

Max. Aperture

F1.53

Angle of View

H: 80°~32°, V:47°~18°

Optical Zoom

4x

Focus Control

Motorized

Close Focus Distance

0.5m(1.64ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~360˚; Tilt:0˚~90˚; Rotation:0˚~360˚

Intelligence

IVS (optional)

Tripwire, Intrusion, Object Abandoned/Missing

Advanced Intelligent Functions

Face Detection, People Counting, Heat Map

Video

Compression

H.265/H.264

Streaming Capability

3 Streams

Resolution

1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480) / VGA(640x480)/ CIF(352×288/342x240)

Frame Rate

Main Stream: 1080P(1~50/60fps)

Sub Stream: D1 (1 ~ 50/60fps)

Third Stream: 1080P(1~50/60fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 24~ 10240Kbps

H.265: 14~ 6144Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(120dB)/ SSA

White Balance

Auto/Natural/Street Lamp/Outdoor/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detetion

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

Support

Smart IR

Support

Defog

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/G.711Mu/AAC/ G.726

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;SMTP;FTP;

DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;NTP;

Bonjour;802.1x;Multicast;ICMP;IGMP;SNMP

Interoperability

ONVIF, PSIA, CGI

Streaming Method

Unicast / Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Mirco SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, Easy4ip

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

N/A

Audio Interface

1/1 channel In/Out

RS485

N/A

Alarm

2/1 channel In/Out

Electrical

Power Supply

DC12V, PoE (802.3at)(Class 4)

Power Consumption

<13W

Environmental

Operating Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Strorage Conditions

-40° C ~ +60° C (-40° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

273.2mm×95.0mm×96.4mm (10.76×3.74×3.79)

Net Weight

1.12Kg (2.47lb)

Gross Weight

1.52Kg (3.35lb)



*******

***********

*

****

**

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

***

*

Save

Save

Save

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Motorized Zoom, Vari-Focal
Day/Night D/N IR, Day/Night, Low light
Factor Bullet
