IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z

In stock
SKU
IPC-HDBW8241E-Z
$360.00

IPC-HDBW8241E-Z

2MP IR AI Dome Network Camera


> 1/2.8” 2Megapixel progressive scan CMOS

> H.265&H.264 triple-stream encoding

> 50/60fps@1080P(1920×1080)

> WDR(140dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC

> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS

> 2.7mm ~13.5mm motorized lens

> Micro SD memory, PoE+

> Max. IR LEDs Length 50m

>without Logo,English firmware
>100% original products manufactured by DAHUA

The delivery time is 25 working days if no stock.

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z without logo

IPC-HDBW8242E-Z4FR

2MP IR Starlight Dome Network Camera

> 1/1.8" 2Megapixel progressive scan CMOS
> H.265&H.264 triple-stream encoding
> 50/60fps@1080P(1920×1080)
> WDR(120dB), Day/Night(ICR), 3DNR,AWB,AGC,BLC
> Multiple network monitoring: Web viewer, CMS(DSS/PSS) & DMSS
> Micro SD memory, PoE+
> Max. IR LEDs Length 100m
> Support face capture, face attributes, face recognition

>without Logo,English firmware
>100% original products manufactured by DAHUA



IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z without logo Overview

Dahua AI series products adopt the most advanced AI technologies, including deep learning algorithms that primarily target people and vehicles, which provides higher flexibility and accuracy for end-users. This enables the Dahua AI series to offer various advanced applications such as Face Recognition, ANPR, Metadata, People Counting, traffic data statistics, etc.The complete lineup of Dahua AI series includes network (PTZ) cameras, network video recorders, servers, and platform management products. Beyond seeing the world, the power of AI allows devices to perceive the environment and understand the world in a better way.Powered by deep-learning Artificial Intelligence algorithms, Dahua’s Perimeter Protection and People counting functions significantly improved accuracy. Perimeter Protection reduces false alarms and decreases pixel count requirements for object detection. Perimeter Protection features custom tripwires based on object type for automation in limited access areas such as pedestrian or vehicle-only zones. This combination of advanced AI analytics and real-time alerts to a desktop or to a mobile client reduces system requirements and resources resulting in greater surveillance system efficiency. People Counting function uses advanced image processing technology to capture depth information from within images. The camera pairs this information with deep learning algorithms to analyze and detect human bodies and track target objects in real time. The camera provides statistics for separate individuals’ entrance and exit with up to 95% counting accuracy

DAHUA Smart Shop solution

IPC-HFW8242E-Z4FR-IRA-LED- DAHUA DH-IPC-HFW8242E-Z4FR-IRA-LED 2MP Starlight Bullet Network Support face capture face attributes, face recognition Camera IPC-HFW8242E-Z4FR-IRA-LED without Logo Functions

The Future has Arrived for AI

Starlight Technology

Featuring Dahua’s Starlight Technology, this camera is ideal for applications with challenging lighting conditions. Its low-light performance delivers usable video with minimal ambient light. Even in extreme low-light conditions, Starlight Technology is capable of delivering color images in near complete darkness .

Ultra WDR Standard

WDR/HDR camera can provide 120dB dynamic range,However, for some scenes with wider contrast range, 120dB is slightly insufficient. By adopting the latest technology, Dahua Cameras can provide an amazing dynamic range up to140dB.

Smart Codec (H.265+ & H.264+)

Smart Codec is the optimized implementation of standard video compression (H.265 & H.264) that uses a scene-adaptive encoding strategy, dynamic GOP, dynamic ROI, flexible multi-frame reference structure and intelligent noise reduction to deliver high-quality video without straining the network. Smart Codec technology reduces bit rate and storage requirements by up to 70% when compared to the standard video compression

IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z without logo Picture

DAHUA IPC-HDBW5121E-Z - DAHUA IPC-HDBW5121E-Z 1.3MP Full HD WDR Network Vandal-proof IR Dome Camera IPC-HDBW5121E-Z Picture



IPC-HDBW8242E-Z4FR - DAHUA DH-IPC-HDBW8242E-Z4FR


IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z without logo Dimension

IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z without logo Installation

IPC-HDBW8242E-Z4FR without logo Installation

DAHUA IPC-HDBW5121E-Z - DAHUA IPC-HDBW5121E-Z 1.3MP Full HD WDR Network Vandal-proof IR Dome Camera IPC-HDBW5121E-Z

IPC-HDBW8242E-Z4FR  Installation


IPC-HDBW8241E-Z - DAHUA DH-IPC-HDBW8241E-Z 2MP IR AI Dome Network Camera with H.265&H.264 triple-stream encoding IPC-HDBW8241E-Z without logo Technical Specifications

*********

Camera

Image Sensor

1/2.8” 2Megapixel progressive scan CMOS

Effective Pixels

1920(H)x1080(V)

RAM/ROM

1024MB/4096MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual, 1/3~1/100000s

Minimum Illumination

0.006Lux/F1.6 (Color,1/3s,30IRE)

0.05Lux/F1.6(Color,1/30s,30IRE)

0Lux/F1.6(IR on)

S/N Ratio

Less than 50dB

IR Distance

Distance up to 50m(164ft)

IR On/Off Control

Auto/Manual

IR LEDs

3

Lens

Lens Type

Motorized

Mount Type

Board-in

Focal Length

2.7~13.5mm motorized

Max. Aperture

F1.6

Angle of View

H: 107.17° ~ 31.82°, V: 56.47° ~ 17.62°

Optical Zoom

5x

Focus Control

Motorized

Close Focus Distance

0.3m(0.98ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

44m(144ft)

18m(59ft)

9m(29ft)

4m(13ft)

T

153m(502ft)

61m(200ft)

31m(102ft)

15m(49ft)

Pan/Tilt/Rotation

Pan/Tilt/Rotation Range

Pan:0˚~355˚; Tilt:0˚~65˚; Rotation:0˚~355˚

Artificial Intelligence

People Counting

Line crossing people counting, Region people counting, Loitering filter

Perimeter Protection

Tripwire, Intrusion(Human&Vehicle classification)

General Intelligence

Event Trigger

Motion detection, Video tampering , Scene changing, Network disconnection , IP address conflict, Illegal Access,Storage anomaly

General Intelligence

N/A

Video

Compression

H.265/H.264/H.264B/H.264H/MJPEG(sub stream)

Smart Codec

Support H.265+/H.264+

Streaming Capability

3 Streams

Resolution

1080P(1920×1080)/ 1.3M(1280x960)/ 720P(1280x720)/ D1(704×576/704x480)/ VGA(640x480)

Frame Rate

Main Stream: 1080P(1~50/60fps)

Sub Stream: D1 (1 ~ 50/60fps)

Third Stream: 1080P(1~19/29fps)

Bit Rate Control

CBR/VBR

Bit Rate

H.264: 24~ 10240Kbps

H.265: 14~ 6144Kbps

Day/Night

Auto(ICR) / Color / B/W

BLC Mode

BLC / HLC / WDR(140dB)/ SSA

White Balance

Auto/Manual

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

Off / On (4 Zone, Rectangle)

Region of Interest

Off / On (4 Zone)

Electronic Image Stabilization (EIS)

Support

Smart IR

Support

Defog

Support

Digital Zoom

16x

Flip

0°/90°/180°/270°

Mirror

Off / On

Privacy Masking

Off / On (4 Area, Rectangle)

Audio

Compression

G.711a/ G.711Mu/ AAC/ G.726

Network

Ethernet

RJ-45 (100/1000Base-T)

Protocol

HTTP;HTTPs;TCP;ARP;RTSP;RTP;UDP;RTCP;SMTP;

FTP;DHCP;DNS;DDNS;PPPOE;IPv4/v6;QoS;UPnP;

NTP;Bonjour;IEEE 802.1x;Multicast;ICMP;IGMP;S

NMP;TLS

Interoperability

ONVIF Profile S&G, API

Streaming Method

Unicast / Multicast

Max. User Access

10 Users/20 Users

Edge Storage

NAS

Local PC for instant recording

Micro SD card 128GB

Web Viewer

IE, Chrome, Firefox, Safari

Management Software

Smart PSS, DSS, DMSS

Smart Phone

IOS, Android

Certifications

Certifications

CE (EN 60950:2000)

UL:UL60950-1

FCC: FCC Part 15 Subpart B

Interface

Video Interface

1 Port(For adjustment only)

Audio Interface

1/1 channel In/Out

RS485

1 port

Alarm

1 channel In: 5mA 5VDC

1 channel Out: 1A 30VDC / 0.5A 50VAC

Electrical

Power Supply

DC12V, AC24V, PoE(802.3at)(Class 4)

Power Consumption

DC12V:5.8W 16.4W(IR on)

PoE:5.3W 14.7W(IR on)

Environmental

Operating Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Storage Conditions

-30° C ~ +60° C (-22° F ~ +140° F) / Less than 95% RH

Ingress Protection

IP67

Vandal Resistance

IK10

Construction

Casing

Metal

Dimensions

Φ159.1mm*117.9mm

Net Weight

1.06Kg (2.34lb)

Gross Weight

1.28Kg (2.82lb)

*******

**

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

**

********

DAHUA IPC-HDBW5121E-Z - DAHUA IPC-HDBW5121E-Z 1.3MP Full HD WDR Network Vandal-proof IR Dome Camera IPC-HDBW5121E-Z

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Motorized Zoom, Vari-Focal
Day/Night D/N IR, Day/Night, Low light
Factor Dome
