IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS

In stock
SKU
IPC-HDBW3841R-ZS
Rating:
100% of 100
$173.89

IPC-HDBW3841R-ZS

8MP IR Vari-focal Dome WizSense Network Camera

> 8MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (3840 × 2160) @20 fps (AI function enabled by default) and supports 8MP (3840 × 2160) @25/30 fps (when AI function disabled)

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 40 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection (Only - ZAS supports), no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection

> Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports)

> Supports max. 256 G Micro SD card

> 12V DC/PoE power supply

> IP67, IK10 protection

> SMD Plus

>DAHUA Logo,English firmware
>100% original products manufactured by DAHUA

DAHUA IPC-HDBW3841R-ZS,DAHUA DH-IPC-HDBW3841R-ZS,IPC-HDBW3841R-ZS,DH-IPC-HDBW3841R-ZS,DH-IPC-HDBW3841RP-ZS,DH-IPC-HDBW3841RN-ZS,dahua cam,dahua mini dome,dahua 8mp camera,smart pss cctv,dahua 5mp ip camera price,dahua ai camera

Special Note:
Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

DAHUA original firmware, Upgradable,2 year guarantee

Enough stock, welcome to order


in Warehouse

IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS

IPC-HDBW3841R-ZS

8MP IR Vari-focal Dome WizSense Network Camera

> 8MP, 1/2.8” CMOS image sensor, low illuminance, high image definition

> Outputs max. 8MP (3840 × 2160) @20 fps (AI function enabled by default) and supports 8MP (3840 × 2160) @25/30 fps (when AI function disabled)

> H.265 codec, high compression rate, low bit rate

> Built-in IR LED, max. IR distance: 40 m

> ROI, SMART H.264+/H.265+, flexible coding, applicable to various bandwidth and storage environments.

> Rotation mode, WDR, 3D DNR, HLC, BLC, digital watermarking, applicable to various monitoring scenes

> Intelligent detection: Intrusion, tripwire (support the classification and accurate detection of vehicle and human)

> Abnormality detection: Motion detection, video tampering, scene changing, audio detection (Only - ZAS supports), no SD card, SD card full, SD card error, network disconnection, IP conflict, illegal access, and voltage detection

> Alarm: 1 in, 1 out (Only - ZAS supports); audio: 1 in, 1 out (Only - ZAS supports)

> Supports max. 256 G Micro SD card

> 12V DC/PoE power supply

> IP67, IK10 protection

> SMD Plus

>,English firmware
>100% original products manufactured by DAHUA

IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS System Overview



 WizSense is a series of AI products and solutions that adopt independent AI chip and deep learning algorithm. It focuses on human and vehicle with high accuracy, enabling users to fast act on defined targets. Based on advanced technologies, WizSense provides intelligent, simple and inclusive products and solutions.

DAHUA Smart Shop solution

With advanced deep learning algorithm, Dahua WizSense 3 Series network camera supports intelligent functions, such as perimeter protection and smart motion detection. With starlight technology, this series camera provides a better image effect in the condition of low illuminance.

IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS Functions

SMD Plus

With intelligent algorithm, Smart Motion Detection technology can categorize the targets that trigger motion detection and filter the motion detection alarm triggered by non-concerned targets to realize effective and accurate alarm.

SMDSMDSMD

SMDSMD

Smart H.265+ & Smart H.264+

With advanced scene-adaptive rate control algorithm, Dahua smart encoding technology realizes the higher encoding efficiency than H.265 and H.264, provides high-quality video, and reduces the cost of storage and transmission.

Perimeter Protection

With deep learning algorithm, Perimeter Protection technology can recognize human and vehicle accurately. In restricted area (such as pedestrian area and vehicle area), the false alarms of intelligent detection based on target type (such as tripwire, intrusion, fast moving, parking detection, loitering detection and gathering detection) are largely reduced.

Detect tripwire and intrusion violationsProcessing Flow

Starlight

Dahua Starlight technology mainly applies to the environment of low illumination, and it can provide clear colorful video. Even in the environment of min. illumination, the technology can guarantee the good image effect.

WDR

With advanced Wide Dynamic Range (WDR) technology, Dahua network camera provides clear details in the environment of strong brightness contrast. The bright and dark area can get clear video even in high brightness environment or with backlight shadow.

Protection (IP67, wide voltage) IP67:

The camera passes a series of strict test on dust and soak. It has dust-proof function, and the enclosure can works normal after soaking in 1 m deep water for 30 minutes. Wide voltage: The camera allows ±30% input voltage tolerance (wide voltage range), and it is widely applied to outdoor environment with instable voltage.

IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS Picture



DAHUA DH-IPC-HDBW3841R-ZAS DAHUA IPC-HDBW3841R-ZS,DAHUA DH-IPC-HDBW3841R-ZS,IPC-HDBW3841R-ZS,DH-IPC-HDBW3841R-ZS,DH-IPC-HDBW3841RP-ZS,DH-IPC-HDBW3841RN-ZS,dahua cam,dahua mini dome,dahua 8mp camera,smart pss cctv,dahua 5mp ip camera price,dahua ai camera


IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS  Dimensions




IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS  Installation


IPC-HDBW3841R-ZS- DAHUA DH-IPC-HDBW3841R-ZS 8MP IR Vari-focal Dome WizSense Network Camera With Starlight SMD Plus Perimeter Protection IPC-HDBW3841R-ZS Technical Specifications

*******

Camera

Image Sensor

1/2.8”8Megapixel progressive CMOS

Max. Resolution

3840 (H) × 2160 (V)

ROM

128 MB

RAM

512 MB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.007 Lux @F1.5

S/N Ratio

>56 dB

Illumination Distance

40 m (131.2 ft)

Illuminator On/Off Control

Auto/Manual

Illuminator Number

2 (IR LED)

Pan/Tilt/Rotation Range

Pan: 0°–355°
Tilt: 0°–75°
Rotation: 0°–355°

Lens

Lens Type

Motorized vari-focal

Mount Type

φ14

Focal Length

2.7 mm–13.5 mm

Max. Aperture

F1.5

Field of View

Horizontal: 113°–31°
Vertical: 58°–17°
Diagonal: 138°–36°

Iris Type

Fixed

Close Focus Distance

0.8 m (2.6 ft)

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

85.3 m (279.9 ft)

34.1 m

(111.9 ft)

17.0 m

(55.8 ft)

8.5 m

(27.9 ft)

T

280.0 m (918.6 ft)

112.0 m (367.5 ft)

56.0 m

(183.7 ft)

28.0 m

(91.9 ft)

Professional, intelligent

Perimeter Protection

Tripwire; intrusion (support the classification and accurate detection of vehicle and human)

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Smart Codec

Smart H.265+/ Smart H.264+

Video Frame Rate

Main stream:

3840 × 2160 @(1–20 fps by default)

3840 × 2160 @(1–25/30 fps when AI function disabled)

sub stream:

704 × 576 @(1–25 fps)/704 × 480 @ (1–30 fps)

third stream:

1920 × 1080 @(1–25/30 fps)

Stream Capability

3 streams

Resolution

8M (3840 × 2160); 6M (3072 × 2048); 5M (3072 × 1728/2592 × 1944); 4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1(704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 3 kbps–8192 kbps
H.265: 3 kbps–8192 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

Scene Self-adaptation

Yes

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D DNR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Smart Illumination

Yes

Image Rotation

0°/90°/180°/270° (Support 90°/270° with 1080p resolution and lower.)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711a; G.711Mu; G726; AAC (Only - ZAS supports)

Alarm

Alarm Event

- ZAS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; audio detection; voltage detection; defocus detection; external alarm; SMD; safety exception
-ZS:
No SD card; SD card full; SD card error; service life warning (only supported by Dahua card); network disconnection; IP conflict; illegal access; motion detection; video tampering; intrusion; tripwire; scene changing; voltage detection; defocus detection; SMD; safety exception

Network

Network

RJ-45 (10/100 Base-T)

SDK and API

Yes

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec

User/Host

20 (Total bandwidth: 72 M)

Storage

Dahua Cloud (only supported by Dahua version); FTP; SFTP; Micro SD card (support max. 256 G); NAS

Browser

IE: IE8; IE9; IE11
Chrome
Firefox

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certification

Certifications

CE-LVD: EN62368-1
CE-EMC: Electromagnetic Compatibility Directive 2014/30/EU
FCC: 47 CFR FCC Part 15, Subpart B
UL/CUL: UL60950-1 CAN/CSA C22.2 No.60950-1-07

Port

Audio Input

1 channel (RCA port) (Only - ZAS supports)

Audio Output

1 channel (RCA port) (Only - ZAS supports)

Alarm Input

1 channel in: 5mA 3V–5V DC (Only - ZAS supports)

Alarm Output

1 channel out: 300mA 12V DC (Only - ZAS supports)

Power

Power Supply

12V DC/PoE (802.3af)

Power Consumption

Basic power consumption: 2.7W (12V DC); 3.3W (PoE)

Max. power consumption (WDR + H.265 + IR LED intensity): 6.8W (12V DC); 8.2W (PoE)

Environment

Operating Conditions

–30°C to +60°C (–22°F to +140°F)/Less than 95% RH

Storage Conditions

–40°C to +60°C (–40°F to +140°F)

Protection Grade

IP67; IK10

Structure

Casing

Metal

Dimensions

88.9 mm × Φ122 mm (3.5" × Φ4.8")

Net Weight

492 g (1.1 lb)

Gross Weight

663 g (1.5 lb)

******

Icctvzone-wholesales DAHUA IP Cameras

*

Icctvzone-wholesales DAHUA IP Cameras
Icctvzone IP surveillance
Icctvzone-wholesales DAHUA NVR

best price of DAHUA camera

***********DAHUA IPC-HDBW3841R-ZS,DAHUA DH-IPC-HDBW3841R-ZS,IPC-HDBW3841R-ZS,DH-IPC-HDBW3841R-ZS,DH-IPC-HDBW3841RP-ZS,DH-IPC-HDBW3841RN-ZS,dahua cam,dahua mini dome,dahua 8mp camera,smart pss cctv,dahua 5mp ip camera price,dahua ai camera****************

More Information
Wired/Wireless Wired
Outdoor use Intdoor use, Outdoor use
Focal Type Fixed
Day/Night Low light
Factor Bullet
Max Resolution 8 MP
