HIKVISION DS-2DP8A845IXG-LF/864(F0) 64MP 360° Panoramic & PTZ Camera

In stock

SKU

DS-2DP8A845IXG-LF/864(F0)

$8,136.00

High quality imaging with 64 MP resolution, up to 8160*3616 @30 fps for panoramic channels
Excellent low-light performance with DarkFighter technology
45x optical zoom and 16x digital zoom provide close up views over expansive areas
Expansive night view with up to 250 m IR distance
With one click on the panoramic channel, the PTZ channel shows the details automatically
Continous and stable manual tracking, auto-tracking, and panorama tracking
Automatic switch between multiple targets
Supports 7 alarm inputs, 2 alarm outputs, 1 audio input, and 1 audio output
Supports AR multi-dimensional arming based on professional platform

High quality imaging with 64 MP resolution, up to 8160*3616 @30 fps for panoramic channels
Excellent low-light performance with DarkFighter technology
45x optical zoom and 16x digital zoom provide close up views over expansive areas
Expansive night view with up to 250 m IR distance
With one click on the panoramic channel, the PTZ channel shows the details automatically
Continous and stable manual tracking, auto-tracking, and panorama tracking
Automatic switch between multiple targets
Supports 7 alarm inputs, 2 alarm outputs, 1 audio input, and 1 audio output
Supports AR multi-dimensional arming based on professional platform

Camera
Image Sensor	[Panoramic channel]: 1/1.8" progressive scan CMOS, [PTZ channel]: 1/1.8" progressive scan CMOS
Max. Resolution	8160*3616
Min. Illumination	[Panoramic channel] Color: 0.0005 Lux (F1.0, AGC ON), B/W: 0.0001 Lux (F1.0, AGC ON);[PTZ channel]: 0.0005 Lux (F1.5, AGC ON), B/W: 0.0001 Lux (F1.5, AGC ON), 0 Lux with IR
Shutter Speed	1 s to 1/30000 s
Day & Night	IR cut filter
Zoom	[PTZ channel] 45x optical, 16x digital
Slow Shutter	Yes

Lens
Focal Length	[panoramic channel] 2.8 mm; [PTZ channel] 7.1~320 mm
FOV	[panoramic channel]Horizontal field of view: 180°Vertical field of view: 85°[PTZ channel]Horizontal field of view: 56.1° to 2.0° (Wide-Tele)Vertical field of view: 33.4° to 1.1° (Wide-Tele)Diagonal field of view: 62.9° to 2.3° (Wide-Tele)
Focus	Auto, semi-auto, manual, rapid focus
Aperture	[panoramic channel] F1.0, [PTZ channel] F1.5
Zoom Speed	[panoramic channel] no, [PTZ channel] approx. 7.8 s

PTZ
Movement Range (Pan)	360°
Movement Range (Tilt)	-15° to 90° (auto flip)
Pan Speed	Pan speed: configurable from 0.1° to 210°/s; preset speed: 240°/s
Tilt Speed	Tilt speed: configurable from 0.1° to 150°/s, preset speed 200°/s
Proportional Pan	[Panoramic channel]: no; [PTZ channel]: yes
Presets	300
Preset Freezing	Yes
Patrol Scan	8 patrols, up to 32 presets for each patrol
Pattern Scan	4 pattern scans, record time over 10 minutes for each scan
Park Action	Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan
3D Positioning	Yes
PTZ Status Display	Yes
Scheduled Task	Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Power-off Memory	Yes

Video
Main Stream	[Panoramic channel]:50Hz: 25fps (32M：81603616×2,55202400×2，8M：40961800×2,38401680×2,27201192×2);60Hz: 30fps (32M：81603616×2,55202400×2，8M：40961800×2,38401680×2,27201192×2) [PTZ channel]:50Hz:25fps (3840×2160,2560×1440,1920×1080,1280×960,1280×720)60Hz: 24fps(3840×2160,2560×1440,1920×1080,1280×960,1280×720)
Sub-Stream	[Panoramic channel]:50Hz: 25fps (32M：1560656×2,704320×2，8M：704320×2,512232×2) 60Hz: 30fps (32M:1560656×2,704320×2，8M：704320×2,512232×2)[PTZ channel]:50Hz:25fps(704×576,640×480,352×288); 60Hz:24fps(704×480,640×480,352×240)
Third Stream	[PTZ channel]:50Hz:25fps (1920×1080,1280×960,1280×720,704×576,640×480,352×288)60Hz: 24fps(1920×1080,1280×960,1280×720,704×480,640×480,352×240)
Video Compression	Main stream: H.265+/H.265/H.264+/H.264Sub-stream: H.265/H.264/MJPEGThird stream: H.265/H.264/MJPEG

Audio
Audio Compression	G.711alaw, G.711ulaw, G.722.1, G.726, MP2L2, AAC, PCM
Audio Sampling Rate	PCM: 8 kHz, 16 kHz, 32 kHz, 48 kHz; MP2L2: 16 kHz, 32 kHz, 48 kHz; AAC: 16 kHz, 32 kHz, 48 kHz

Network
Protocols	IPv4/IPv6, HTTP, HTTPS, 802.1x, QoS, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View	Up to 20 channels
API	Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK, ISUP
User/Host	Up to 32 users. 3 user levels: administrator, operator, and user
Security	Authenticated username and password, MAC address binding, HTTPS encryption, 802.1X authenticated access, IP address filter
Network Storage	NAS (NFS, SMB/CIFS), ANR
Client	iVMS-4200, HikCentral Pro, Hik-Connect
Web Browser	IE10-11, Chrome 57+, Firefox 52+, Safari 12+

Image Parameters Switch	Yes
Image Settings	Saturation, brightness, contrast, sharpness, gain, and white balance adjustable by client software or web browser
Day/Night Switch	Day, night, auto, scheduled-switch
Wide Dynamic Range (WDR)	[Panoramic channel] digital WDR, [PTZ channel] 120 dB
SNR	≥ 55 dB
Defog	[Panoramic channel]: no; [PTZ channel]: optical defog
Image Stabilization	OIS，EIS
Image Enhancement	BLC, HLC, 3D DNR
Privacy Mask	Programmable polygon privacy masks (8 for panoramic channel, 24 for PTZ channel), mask color or mosaic configurable
Regional Focus	Yes
Regional Exposure	Yes

Interface
Ethernet Interface	1 RJ45 10M/100M/1000M self-adaptive Ethernet port
On-board Storage	Built-in memory card slot, support microSD/microSDHC/microSDXC cards, up to 256 GB
Audio	1 input (line in), max. input amplitude: 2-2.4 vpp, input impedance: 1 KΩ ± 10%; 1 output (line out), line level, output impedance: 600 Ω
Alarm	7 alarm inputs, 2 alarm outputs
RS-485	1 RS-485 (Half duplex, HIKVISION, Pelco-P, Pelco-D, self-adaptive)
Reset	Yes
Fiber Optical	1 FC interface, built-in fiber module, 1000M, TX1310/RX1550 nm wavelength, single module fiber, up to 20 km transmission distance

Event
Smart Event	Intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection，face capture
Linkage	memory card video recording,alarm output,sending email,notify surveillance center, upload to FTP,NAS video recording,audible warning
Smart Tracking	Manual tracking, auto-tracking, panorama tracking. Support patrol tracking among multiple detection scenes

General
Power	36 VDC
Dimension	Ø 433.5 mm x 430.4 mm (Ø 17.07" x 16.94")
Weight	Approx. 18 kg (39.68 lb.)
Material	ADC12
Operating Condition	Temperature: -40°C to 70°C (-40°F to 158°F)，Humidity: ≤ 95%
Wiper	No
Demist	Yes
Power Consumption andCurrent	max. 135 W, including max. 12 W for IR

Approval
Safety	UL (UL 62368-1); CB (IEC 62368-1: 2014+A11); CE-LVD (EN 62368-1:2014/A11:2017);
Environment	CE-RoHS (2011/65/EU); WEEE (2012/19/EU); Reach (Regulation (EC) No 1907/2006)
Protection	IP67 Standard, Lightning Protection, Surge Protection and Voltage Transient Protection, ±6kV Line to Gnd, ±3kV Line to Line, IEC61000-4-5, IK10

Available models:

DS-2DP8A845IXG-LF/864(F0)
