HAP301 - DAHUA DH-HAP301 Hi-fidelity Pickup With Noise reduction,Built-in high-speed CPU, real-time processing audio signal, low latency

In stock

SKU

HAP301

$66.00

HAP301

Hi-fidelity Pickup

> CPU built-in audio sampling module, low interference from the hardware
> Smart audio crack protection, auto low microphone sensitivity to meet
> Adopts wide dynamic range processing technology for the valid audio
> High-sensitivity microphone, omni-directional pickup, clear audio, high
> Noise reduction via the algorithm to enhance signal definition.
> Auto gain and compensate the human voice frequency. Exaggerates the
> It can effectively reduce the indoor reverberation resulting from the
> It supports screaming control function and can greatly enhance the
> Built-in high-speed CPU, real-time processing audio signal, low latency.
> Built-in lighting protection, power two-polarity misconnection
> CE, FCC compliance.

> 100% original products manufactured by DAHUA

Special Note:

Because the product always maintains a fast inventory flow, the model you ordered may take longer to produce (about 3 weeks or more days), we will push the factory and try our best to ship to you as soon as possible, thank you for your waiting.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

HAP301 - DAHUA DH-HAP301 Hi-fidelity Pickup With Noise reduction,Built-in high-speed CPU, real-time processing audio signal, low latency

HAP301

Hi-fidelity Pickup

> 100% original products manufactured by DAHUA

HAP301 - DAHUA DH-HAP301 Hi-fidelity Pickup With Noise reduction,Built-in high-speed CPU, real-time processing audio signal, low latency Picture

HAP301 - DAHUA DH-HAP301 Hi-fidelity Pickup With Noise reduction,Built-in high-speed CPU, real-time processing audio signal, low latency

Dimensions

HAP301 - DAHUA DH-HAP301 Hi-fidelity Pickup With Noise reduction,Built-in high-speed CPU, real-time processing audio signal, low latency

Installation

HAP301 - DAHUA DH-HAP301 Hi-fidelity Pickup With Noise reduction,Built-in high-speed CPU, real-time processing audio signal, low latency Specification

Technical Specifications

***

Performance

Pickup Range

1 square meter–150 square meters (10.76 sq.ft–1614.59 sq.ft)

Audio Transmission Distance

3000 m (9842.52 ft)

Frequency Response

20 Hz–20 kHz

Sensitivity

-38 dB

SNR

85 dB (1 m 40 dB audio source SPL) 52 dB(10 m 40 dB audio source SPL)1 kHz at 1 Pa

Pointing Features

Omni-directional

Gain Adjustment

0 VPP–4.6 VPP adjustable (75 dB sound pressure 1 kHz)

Dynamic Range

106 dB (1 kHz at Max dB SPL)

Distortion

≤0.3% (74 dB sound pressure, A weighted)

Max. Sound Pressure

120 dB SPL (1 kHz,THD 1%)

Output Resistance

25 Ω non-balanced

Output Signal Amplitude

2.5 VPP/-25 dB

Microphone

High-fidelity micro electromechanical system (MEMS) silicon microphone

Signal Processing

Digital NR, reverberation, human voice enhancement, screaming control

Protection

8kV Air,6kV contact ESD lightening protection, power polarity misconnection protection

Electrical

Drive Capability

Built-in preamplifier circuit

Connection Mode

3 lead wire: (power, audio, public GRD)

Transmission Cable

3-Pin mm² RVVP shielded cable

Power Supply

12V DC (9V-18V)

Power Consumption

0.72W (60mA)

Environmental

Operating Temperature

-20 °C to +60 °C (-4 °F to +140 °F)

Operating Humidity

≤95%RH

Storage Temperature

0°C to +40°C (+32°F to +104°F)

Storage Humidity

≤95%RH

Construction

Color

Metal Silver

Casing

Aluminum alloy

Dimensions

Φ70 mm × 21 mm (Φ2.76 " × 0.83 ")

Net Weight

0.11 kg (0.24 lb)

Gross Weight

0.16 kg (0.35 lb)

Certifications

FCC: 47 CFR Part 15,Subpart B:2016
CE: EN 55032:2015(Class B),EN50130-4:2011+A1:2014,EN55024:2010+A1:2015
