HIKVISION DS-UVC-P18 4K Video Conference PTZ Camera

In stock
SKU
DS-UVC-P18
$10,000.00
  • 8 MP CMOS
  • High quality imaging with 3840 × 2160 resolution
  • 3 mm to 15 mm varifocal lens, auto focus, × 5 optical zoom, × 4 digital zoom
  • Min. Illumination: 0.2 Lux @ (F1.8 to 2.8 ,AGC ON)
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • AGC for self-adaptive brightness
  • USB Type-C interface, supporting USB 3.0 protocol. Plug-and-play, no need to install driver software
  • Dual-microphone built into the PTZ camera with clear sound
  • 8 MP CMOS
  • High quality imaging with 3840 × 2160 resolution
  • 3 mm to 15 mm varifocal lens, auto focus, × 5 optical zoom, × 4 digital zoom
  • Min. Illumination: 0.2 Lux @ (F1.8 to 2.8 ,AGC ON)
  • Clear imaging against strong back light due to 120 dB true WDR technology
  • AGC for self-adaptive brightness
  • USB Type-C interface, supporting USB 3.0 protocol. Plug-and-play, no need to install driver software
  • Dual-microphone built into the PTZ camera with clear sound
Camera
Image Sensor1/2.8" 4KCMOS
Max. Resolution3840 (H) × 2160 (V)
Min. Illumination0.2 Lux @ (F1.8 to 2.8,AGC ON)
Shutter TimePAL: 1/25 s to 1/10,000 s;NTSC: 1/30 s to 1/10,000 s
Angle AdjustmentPan: -165° to 165°,Tilt: -30° to 30°
Optical Zoom× 5
Digital Zoom× 4
Lens
Lens TypeVarifocal lens, 3 to 15 mm
Focal Length & FOVHorizontal FOV: 85° to 24°Vertical FOV: 53° to 14°Diagonal FOV: 93° to 27°
Depth of FieldWide: 0.1 m to ∞; Tele: 0.5 m to ∞
Microphone
TypeECM
Polar Pattern360° omni-directional
Pickup DistanceIn a radius of up to 5 m
Amountdual mic
Frequency Response100 Hz to 8 kHz
Sensitivity-32 ± 3 dBV/Pa
SNR70 dB(A)
Sampling Rate16 kHz/32 kHz/48 kHz
Functions
Image FunctionAuto/Manual White Balance, Backlight Compensation, Left/Right Flip / Up/Down Flip/Center Mirror
Audio FunctionSupports steady and transient smart noise reduction, automatic gain control, echo suppression, time domain equalization algorithm, ambient noise suppression and enhanced vocals to enhance speech quality and offer audio in high quality
LED IndicatorFlashing white: powering on and startingSolid white: normally workingSolid red: muteLight off: standby
Auto FocusYes
Communication
Communication MethodUSB cable
Wired Communication DistanceCable length: 2 m. Transmission distance: 2 m.
Frame RateMJPG/H.264:3840 × 2160 @30 fps/25 fps2560 × 1440 @30 fps/25 fps1920 × 1080 @60 fps/50 fps/30 fps/25 fps1280 × 960 @60 fps/50 fps/30 fps/25 fps1280 × 720 @60 fps/50 fps/30 fps/25 fps640 × 480 @60 fps/50 fps/30 fps/25 fps640 × 360 @60 fps/50 fps/30 fps/25 fpsYUY2:1920 × 1080 @30 fps/25 fps1280 × 960 @30 fps/25 fps1280 × 720 @30 fps/25 fps640 × 480 @30 (default) /25fps640 × 360 @30 fps/25 fpsNV12:1920 × 1080 @30 fps/25 fps1280 × 960 @30 fps/25 fps1280 × 720 @30 fps/25 fps640 × 480 @30 fps/25 fps640 × 360 @30 fps/25 fps
Wide Dynamic Range (WDR)≥120 dB
Interface
Device InterfaceUSB Type C interface, Power interface
Audio1 line in, 3.5 mm connector1 line out, 3.5 mm connector
CableUSB Cable: Type C to Type A interfaceAdapter Extension Cable: DC plug to DC socket
Compatibility
System RequirementWindows 7/8/10/11 (resolution higher than 1080 p is only available in Windows 8.1 and above version)Android 8.1 and above versionLinux 4.14 and above versionmacOS 10.12 and above version
General
Power12 VDC ± 5%, max. 10.2 W
Operating Condition-10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
MaterialMetal, plastic
ColorSpace gray
Dimension145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7")
Package Dimension365 mm × 210 mm × 183 mm (14.37" × 8.27" × 7.2")
WeightApprox. 960 g (2.12 lb.)
With Package WeightApprox. 2350 g (5.18 lb.)
Accessory
Packing ListCamera (including lens cover) × 1Remote Control × 1Power Adapter (1.2 m) × 1Power Adapter Extension Cable (3 m) × 1Power Adapter Plug × 3 (for British, American, and European standards)USB 3.0 Cable (2 m) × 1Bracket × 1Screws × 1Battery × 2Quick Start Guide × 1

Available models:

DS-UVC-P18
