HIKVISION DS-UVC-P12 2MP Video Conference PTZ Camera

In stock

SKU

DS-UVC-P12

Be the first to review this product

$10,000.00

2 MP CMOS
High quality imaging with 1920 × 1080 resolution
3 mm to 15 mm varifocal lens, auto focus, × 5 optical zoom, × 4 digital zoom
Min. Illumination: 0.2 Lux @ (F1.8 to 2.8 ，AGC ON)
Clear imaging against strong back light due to 120 dB true WDR technology
AGC for self-adaptive brightness
USB Type-C interface, supporting USB 2.0 protocol. Plug-and-play, no need to install driver software
Dual-microphone built into the PTZ camera with clear sound

Skip to the end of the images gallery

Skip to the beginning of the images gallery

2 MP CMOS
High quality imaging with 1920 × 1080 resolution
3 mm to 15 mm varifocal lens, auto focus, × 5 optical zoom, × 4 digital zoom
Min. Illumination: 0.2 Lux @ (F1.8 to 2.8 ，AGC ON)
Clear imaging against strong back light due to 120 dB true WDR technology
AGC for self-adaptive brightness
USB Type-C interface, supporting USB 2.0 protocol. Plug-and-play, no need to install driver software
Dual-microphone built into the PTZ camera with clear sound

Camera
Image Sensor	1/2.8" 2 MP CMOS
Max. Resolution	1920 (H) × 1080 (V)
Min. Illumination	0.2 Lux @ (F1.8 to 2.8，AGC ON)
Shutter Time	PAL: 1/25 s to 1/10,000 s;NTSC: 1/30 s to 1/10,000 s
Angle Adjustment	Pan: -165° to 165°,Tilt: -30° to 30°
Optical Zoom	× 5
Digital Zoom	× 4

Lens
Lens Type	Varifocal lens, 3 to 15 mm
Focal Length & FOV	Horizontal FOV: 85° to 24°Vertical FOV: 53° to 14°Diagonal FOV: 93° to 27°
Depth of Field	Wide: 0.1 m to ∞; Tele: 0.5 m to ∞

Microphone
Type	ECM
Polar Pattern	360° omni-directional
Pickup Distance	In a radius of up to 5 m
Amount	dual mic
Frequency Response	100 Hz to 8 kHz
Sensitivity	-32 ± 3 dBV/Pa
SNR	70 dB(A)
Sampling Rate	16 kHz/32 kHz/48 kHz

Functions
Image Function	Auto/Manual White Balance, Backlight Compensation, Left/Right Flip / Up/Down Flip/Center Mirror
Audio Function	Supports steady and transient smart noise reduction, automatic gain control, echo suppression, time domain equalization algorithm, ambient noise suppression and enhanced vocals to enhance speech quality and offer audio in high quality
LED Indicator	Flashing white: powering on and startingSolid white: normally workingSolid red: muteLight off: standby
Auto Focus	Yes

Communication
Communication Method	USB cable
Wired Communication Distance	Cable length: 4.5 m. Transmission distance: 4.5 m.

Frame Rate	MJPG/H.264:1920 × 1080 @60 fps/50 fps/30 fps/25 fps1280 × 960 @60 fps/50 fps/30 fps/25 fps1280 × 720 @60 fps/50 fps/30 fps/25 fps640 × 480 @60 fps/50 fps/30 fps/25 fps640 × 360 @60 fps/50 fps/30 fps/25 fpsYUY2:1920 × 1080 @5 fps1280 × 960 @10 fps1280 × 720 @15 fps640 × 480 @30 (default) /25 fps640 × 360 @30 fps/25 fpsNV12:1920 × 1080 @5 fps1280 × 960 @10 fps1280 × 720 @15 fps640 × 480 @30 fps/25 fps640 × 360 @30 fps/25 fps
Wide Dynamic Range (WDR)	≥120 dB


Frame Rate

MJPG/H.264:1920 × 1080 @60 fps/50 fps/30 fps/25 fps1280 × 960 @60 fps/50 fps/30 fps/25 fps1280 × 720 @60 fps/50 fps/30 fps/25 fps640 × 480 @60 fps/50 fps/30 fps/25 fps640 × 360 @60 fps/50 fps/30 fps/25 fpsYUY2:1920 × 1080 @5 fps1280 × 960 @10 fps1280 × 720 @15 fps640 × 480 @30 (default) /25 fps640 × 360 @30 fps/25 fpsNV12:1920 × 1080 @5 fps1280 × 960 @10 fps1280 × 720 @15 fps640 × 480 @30 fps/25 fps640 × 360 @30 fps/25 fps

Wide Dynamic Range (WDR)

≥120 dB

Interface
Device Interface	USB Type C interface, Power interface
Audio	1 line in, 3.5 mm connector1 line out, 3.5 mm connector
Cable	USB Cable: Type C to Type A interfaceAdapter Extension Cable: DC plug to DC socket

Compatibility
System Requirement	Windows 7/8/10/11Android 8.1 and above versionLinux 4.14 and above versionmacOS 10.12 and above version

General
Power	12 VDC ± 5%, max. 8.4 W
Operating Condition	-10 °C to 45 °C (14 °F to 113 °F). Humidity 90% or less (non-condensing)
Material	Metal, plastic
Color	Space gray
Dimension	145.3 mm × 145.6 mm × 145.8 mm (5.7" × 5.7" × 5.7")
Package Dimension	365 mm × 210 mm × 183 mm (14.37" × 8.27" × 7.2")
Weight	Approx. 960 g (2.12 lb.)
With Package Weight	Approx. 2400 g (5.29 lb.)

Accessory
Packing List	Camera (including lens cover) × 1Remote Control × 1Power Adapter (1.2 m) × 1Power Adapter Extension Cable (3 m) × 1Power Adapter Plug × 3 (for British, American, and European standards)USB 2.0 Cable (4.5 m) × 1Bracket × 1Screws × 1Battery × 2Quick Start Guide × 1

Available models:

DS-UVC-P12
