Camera

Image Sensor

1/1.8”8Megapixel progressive CMOS

Max. Resolution

3840 (H) × 2160 (V)

ROM

4 GB

RAM

2 GB

Scanning System

Progressive

Electronic Shutter Speed

Auto/Manual 1/3 s–1/100,000 s

Min. Illumination

0.003 Lux@F1.2 (Color,30IRE)

0.0003 Lux@F1.2 (B/W,30IRE)

0 Lux (Illuminator on)

S/N Ratio

> 56 dB

Illumination Distance

80 m

Illuminator On/Off Control

Auto/Manual

Illuminator Number

6 (Warm light)

Lens

Lens Type

Motorized vari-focal

Mount Type

Module

Focal Length

8 mm–56 mm

Max. Aperture

F1.2 (Constant)

Field of View

Horizontal: 40° (W)–9° (T)
Vertical: 22° (W)–5° (T)
Diagonal: 46° (W)–10° (T)

Iris Type

Auto

Close Focus Distance

W: 2 m (6.6 ft)
T: 3 m (9.8ft)

DORI Distance

Lens

Detect

Observe

Recognize

Identify

W

151.1 m (495.4 ft)

60.7 m (199.1 ft)

30.3 m (99.4 ft)

15.1 m (49.5 ft)

T

400.0 m (1312.3 ft)

160.0m (524.9 ft)

80.0m (262.5 ft)

40.0m (131.2 ft)

Smart Event

IVS

Abandoned object; missing object

Professional, intelligent

IVS (Perimeter Protection)

Tripwire; intrusion; fast moving (the three functions support the classification and accurate detection of vehicle and human); loitering detection; people gathering; parking detection

Face Detection

Face detection; track; optimization; snapshot; report high quality picture; face enhancement; face exposure; face attribute extract, 6 attributes and 8 expressions: Gender, age, glasses, expressions (anger, calm, happiness, sadness, disgust, surprise, confusion and fear), mask, beard; face matting setting: Face, single inch photo; three snapshot methods: Real-time snapshot, optimization snapshot, quality priority; face angle filter; optimization time setting

People Counting

Support the people counting of tripwire, people counting in area, and displaying and outputting yearly/monthly/daily reports
Support queue management, and displaying and outputting monthly/daily reports
Support 4 rules configuration for people counting of tripwire, 4 rules configuration for people counting in area , 4 rules configuration for queue management

ANPR

ANPR, track, priority, snapshot

Vehicle attributes: license plate, vehicle type, vehicle color, vehicle brand

Other attributes: sun visor, seat belt, smoking, phoning, in-car accessories, annual vehicle inspection mark

Video Metadata

Support human body, human face, motor vehicle and non-motor vehicle image capture and attributes extraction.

Intelligent Search

Work together with Smart NVR to perform refine intelligent search, event extraction and merging to event videos.

Video

Video Compression

H.265; H.264; H.264H; H.264B; MJPEG (only supported by the sub stream)

Smart Codec

Smart H.265+/H.264+

Video Frame Rate

Main Stream: 3840 × 2160 (1-25/30 fps)

Sub stream: 704 × 576 (1-25 fps)/704 × 480 (1–30 fps)

Third stream: 1920 × 1080 (1-25/30 fps)

Fourth stream: 1920 × 1080 (1-25/30 fps)

Fifth stream: 704 × 576 (1-25fps)/704 × 480 (1–30 fps)

Stream Capability

5 streams

Resolution

8M (3840 × 2160); 6M (3072 × 2048/3072 × 1728); 5M (2592 × 1944)/4M (2688 × 1520); 3M (2048 × 1536/2304 × 1296); 1080p (1920 × 1080); 1.3M (1280 × 960); 720p (1280 × 720); D1 (704 × 576/704 × 480); VGA (640 × 480); CIF (352 × 288/352 × 240)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 9 kbps–17664 kbps
H.265: 9 kbps–17664 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

HLC

Yes

WDR

120 dB

Scene Self-adaptation (SSA)

Yes

White Balance

Auto/natural/street lamp/outdoor/manual/regional custom

Gain Control

Auto/Manual

Noise Reduction

3D NR

Motion Detection

OFF/ON (4 areas, rectangular)

Region of Interest (RoI)

Yes (4 areas)

Electronic Image Stabilization (EIS)

Yes

Smart Illumination

Yes

Defog

Yes

Image Rotation

0°/90°/180°/270°

(Support 90°/270° with 1080p resolution and lower)

Mirror

Yes

Privacy Masking

4 areas

Audio

Audio Compression

G.711A; G.711Mu; G.726; G.723

Alarm Event

Alarm Event

No SD card; SD card full; SD card error; network disconnection; illegal access; security exception; IP conflict; motion detection; video tampering; intrusion; tripwire; abandoned object; missing object; fast moving; parking detection; people gathering; loitering detection; scene changing;

audio detection; defocus detection; people counting; people counting in area; face detection; video metadata; external alarm; voltage detection

Network

Network

RJ-45 (10/100/1000 Base-T)

5G

Support 5G module (N41, N78, and N79 frequency range), and NSA and SA network

SDK and API

Yes

Cyber Security

Video encryption; firmware encryption; configuration encryption; Digest; WSSE; account lockout; security logs; IP/MAC filtering; generation and importing of X.509 certification; syslog; HTTPS; 802.1x; trusted boot; trusted execution; trusted upgrade

Protocol

IPv4; IPv6; HTTP; HTTPS; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; QoS; UPnP; NTP; Multicast; ICMP; IGMP; NFS; SAMBA; PPPoE; 802.1x; SNMP; Bonjour

Interoperability

ONVIF (Profile S/Profile G/Profile T); CGI; P2P; Milestone; Genetec

User/Host

20 (Total bandwidth: 80 M)

Storage

FTP; SFTP; Micro SD card (support max. 256 G); NAS

Browser

IE: IE9 and later
Chrome: 50 and later
Firefox: 48 and later

Management Software

Smart PSS; DSS; DMSS

Mobile Phone

IOS; Android

Certifications

Certification

CE-LVD: EN62368-1CE-EMC: Electromagnetic Compatibility Directive 2014/30/EUFCC: 47 CFR FCC Part 15,Support B

Port

RS-485

1 (baud rate range: 1200 bps–115200 bps)

Audio Input

2 channel (RCA port)

Audio Output

1 channel (RCA port)

Alarm Input

7 channels in: 5mA 3V–5V DC

Alarm Output

3 channels out: 1,000mA 30V DC/500mA 50V AC

Power

Power Supply

12V DC

Power Consumption

Basic power consumption: 5.2W (12V DC)
Max. power consumption (ICR + warm light full intensity + 5G acquiring): 25.5W (12V DC)

Environment

Operating Conditions

–30°C to +60°C (–22°F to +140°F)/Less than 95% RH

Protection Grade

IP67

Construction

Casing

Metal + Plastic

Dimensions

404.3 mm × 163.8 mm × 211.8 mm

(15.9 × 6.4" × 8.3") (L × W × H)

Net Weight

4.02 kg (8.9 lb)

Gross Weight

4.98 kg (11 lb)
