Thermal

Detector Type

Vanadium oxide uncooled focal plane detector

Effective Pixels

400 (H) × 300 (V)

Pixel Pitch

12 μm

Spectral Range

8 μm–14 μm

Sensitivity (NETD)

<35 mK (@f/1.0)

Focal Length

25 mm; 50 mm

Field of View

25 mm: H: 11.0°; V: 8.2°

50 mm: H: 5.5°; V: 4.1°

Thermal Focus Control

Fixed-focal

Close Focus Distance

25 mm: 1 m (3.28 ft)

50 mm: 1 m (3.28 ft)

Detection Distance①

25 mm: Vehicle: 3,205 m (10,515.09 ft);

Human: 1,041 m (3,415.35 ft)

50 mm: Vehicle: 6,410 m (21,030.18 ft);

Human: 2,083 m (6,833.99 ft)

Recognition Distance②

25 mm: Vehicle: 786 m (2,578.74 ft);

Human: 268 m (879.27 ft)

50 mm: Vehicle: 1,572 m (5,157.48 ft);

Human: 536 m (1,758.53 ft)

Identification Distance③

25 mm: Vehicle: 397 m (1,302.49 ft);

Human: 134 m (439.63 ft)

50 mm: Vehicle:794 m (2,604.99 ft);

Human: 268 m (879.27 ft)

Note:

①Detection Distance: Detects objects, but cannot recognize their characteristics (objects must cover more than 3.6 pixels of the image).

②Recognition Distance: Classifies objects into general categories, such as human, vehicle (the object must cover more than 14 pixels of the image).

③Identification Distance: Classifies objects into specific categories based on their characteristics, such as engineering truck, car (the object must cover more than 28 pixels of the image).

Digital Detail Enhancement (DDE)

Yes

Digital Zoom

19 levels

Thermal AGC

Auto/Manual

Thermal Noise Reduction

2D NR/3D NR

Image Flip

180°; Mirror

Color Palettes

18 (white hot/black hot/fusion/rainbow/golden autumn/midday/iron red/amber/jade/sunset/icefire/painting/pomegranate/emerald /spring/summer/autumn/winter)

Visible

Image Sensor

1/1.8" CMOS

Max. Resolution

2688 (H) × 1520 (V)

Pixel

4 MP

Horizontal Definition

Center ≥ 1200 TVL

Edge ≥ 900 TVL

Min. Illumination

Color: 0.001 lux@F1.4

Black & white: 0.0001 lux@F1.4

0 lux (IR on)

Visible AGC

Auto/Manual

Visible Noise Reduction

2D NR/3D NR

S/N Ratio

≥55 dB

White Balance

Auto; manual; indoor; outdoor; tracking; sodium lamp; street lamp; natural

Defog

Optical defog

Visible Image Stabilization

Optical Image Stabilization

Electronic Shutter Speed

1 s–1/30,000 s (auto/manual)

BLC

Yes

WDR

Yes

HLC

Yes

Digital Zoom

Yes

Day/Night

Auto (ICR); Color; B/W

Iris Control

Auto

Image Flip

Yes

Exposure Compensation

Yes

Visible Focus Control

Auto/semi-auto/manual

Focal Length

6 mm–336 mm

Zoom Speed

<8.8 s

Field of View

H: 64.4°–1.28°

V: 38.37°–0.72°

Close Focus Distance

0.1 m–5 m (0.33 ft–16.4 ft)

Optical Zoom

56×

Aperture

F1.5–F5.3

Illuminator On/Off Control

Auto/Manual

Illumination Distance

150 m (492.13 ft)

Audio and Video

Video Compression

H.265; H.264M; H.264H; H.264B; MJEPG

Resolution

Thermal:

Main stream: 1280 × 1024; 1280 × 960; 1280 × 720; 400 × 300; 1280 × 960 (default);

Sub stream: 640 × 512; 640 × 480; 400 × 300; 400 × 300 (default);

Visible:

Main stream: 4M (2688 × 1520); 2M (1920 × 1080); 720p (1280 × 720); D1 (704 × 576); 4M (2688 × 1520) (default);

Sub stream:D1 (704 × 576); CIF (352 × 288); CIF (352 × 288) (default);

Video Frame Rate

Thermal (50 Hz):

Main stream: 1 fps–50 fps, 50 fps by default Sub stream: 1 fps–25 fps, 15 fps by default

Visible (50 Hz):

Main stream: 1 fps–25 fps, 25 fps by default Sub stream: 1 fps–25 fps, 15 fps by default

Thermal (60 Hz):

Main stream: 1 fps–60 fps, 60 fps by default Sub stream: 1 fps–30 fps, 15 fps by default

Visible (60 Hz): Main stream: 1 fps–30 fps, 30 fps by default Sub stream: 1 fps–30 fps, 15 fps by default

Audio Compression

G.711a; G.711mu; PCM

Image Encoding Format

JPEG

PTZ

Pan/Tilt Range

Pan: 0° to +360°

Tilt: –27° to +90°

Manual Control Speed

Pan: 0.1°/s to 200°/s

Tilt: 0.1°/s to 120°/s

Preset Speed

Pan: 0.1°/s to 240°/s

Tilt: 0.1°/s to 200°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Privacy Masking

4 by default

Idle Motion

Preset; pattern; tour; pan; scan

Timing Task

Preset; pattern; tour; pan; scan

Position Display

On/Off

Wiper

Auto rain-sensing. Supports setting wiper running times, frequency, and period.

3D Positioning

Yes

Function

Two-way Audio

Yes

Network Protocol

IPv4/IPv6; HTTP; HTTPS; 802.1x; Qos; FTP; SMTP; UPnP; SNMP; DNS; DDNS; NTP; RTSP; RTP; TCP; UDP; IGMP; ICMP; DHCP; PPPoE; ONVIF

Region of Interest (RoI)

Yes (customizable)

Storage

FTP; Micro SD card (optional)

Micro SD Card (Max.)

512 GB

Interoperability

ONVIF; CGI

Browser

IE: IE8 and later
Chrome: 42 and earlier
Firefox: 42 and earlier

User/Host

Up to 20 (total bandwidth: 64 MB)

Security

Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access

User Management

Up to 20 users; supports multi-level user permissions (2 levels): management group and user group

Malfunction Detection

Network disconnection detection; IP conflict detection; memory card state detection; memory space detection

PIP

Yes

Intelligence

Heat Detection

Yes

Cold/Hot Spot Trace

Yes

IVS (Perimeter Protection)

Yes. Supports tripwire and intrusion.

Target Distinction

Human/Vehicle Classification

Target Tracking

Yes

Target Filtering

Yes

Smoke Detection

Yes

Boat Detection

Yes

Engineering Truck Detection

Yes

Panoramic PTZ

Yes

Port

Analog Output

1.0V[p-p]/75 Ω; PAL or NTSC; BNC port

Network Port

1 × RJ-45 (10/100 Base-T)

Alarm Input

7

Alarm Output

2

Audio Input

1

Audio Output

1

RS-485

1

Power

Power Supply

24–57 VDC

Power Consumption

Basic: 30 W

Max: 50 W (illuminator)

Environment

Operating Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Operating Humidity

≤95%

Storage Temperature

–50 °C to +80 °C (–58 °F to +176 °F)

Physical Characteristics

Protection

IP66

Reliability

Surge protection: 6 kV
Air discharge: 15 kV
Contact discharge: 8 kV

Structure

Product Dimensions

300 mm × 300 mm × 500 mm (11.81" × 11.81" × 19.69") (L × W × H)

Packaging Dimensions

435 mm × 435 mm × 666 mm (17.13" × 17.13" × 26.22") (L × W × H)

Net Weight

≤13 kg (28.66 lb)

Gross Weight

≤16 kg (35.27 lb)

Heat Detection Distance

Focal Length

Max. Distance

25 mm

1,500 m (4,921.26 ft)

50 mm

3,000 m (9,842.52 ft)

Note:

The table displays the measured distances obtained from using the target size 2 m × 2 m for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.

The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.

Perimeter Protection Distance

Focal Length

Distance (Human)

Distance (Vehicle)

25 mm

175 m (574.15 ft)

525 m (1,722.44 ft)

50 mm

350 m (1,148.29 ft)

1,050 m (3,444.88 ft)

Note:

The table displays the measured distances obtained from using the target sizes

1.8 m × 0.5 m (human) and 1.4 m × 4 m (vehicle) for testing in an environment where the temperature is 23 °C and the relative humidity is below 60%.

The table is for reference only. The distances within it are subject to actual conditions including atmospheric conditions, target size, the installation site, and more.
