Thermal

Detector Type

Vanadium Oxide Uncooled Focal Plane Detector

Max. Resolution

640 × 512

Pixel Pitch

17μm

Spectral Range

8μm–14μm

Thermal Sensitivity (NETD)

≤ 40mK@f/1.0

Focal Length

7.5 mm

13 mm

25 mm

Field of View

H: 91.2° ×

V: 70.3°

H: 48.9° ×

V: 38.8°

H: 24.6° ×

V: 19.8°

Effective Distance
Human (1.8 m × 0.5 m)

D: 221 m

(725.07 ft)

R: 57 m

(187.01 ft)

I: 28 m

(91.86 ft)

D: 382 m

(1253.28 ft)

R: 98 m

(321.52 ft)

I: 49 m

(160.76 ft)

D: 735 m

(2411.42 ft)

R: 189 m

(620.08 ft)

I: 95 m

(311.68 ft)

Effective Distance
Vehicle (4.0 m × 1.4 m)

D: 558 m

(1830.71 ft)

R: 147 m

(482.28 ft)

I: 74 m

(242.78 ft)

D: 1020 m

(3346.47 ft)

R: 255 m

(836.61 ft)

I: 127 m

(416.67 ft)

D: 1961 m

(6433.73 ft)

R: 490 m

(1607.61 ft)

I: 245 m

(803.81 ft)

Focus Mode

Athermalized

Aperture

F1.0

Digital Detail
Enhancement (DDE)

Yes

Image Stabilization

Electronic Image Stabilization

Digital Zoom

24×

AGC

Auto; Manual

Noise Reduction

2D NR; 3D NR

Image Flip

90°/180°/mirror

Intelligence

Advanced Intelligence

Fire Detection & Alarm
Cold & Hot Spot Trace

Tripwire & Intrusion
Human & Vehicle Classification

Temperature Measurement

Temperature Range

Low Temperature Mode: -20°C to +150°C (-4°F to +302°F)
High Temperature Mode: 0°C to +550°C (+34°F to +1022°F)

Temperature Accuracy

Max (±2°C, ±2%)
Operating Temperature: -20°C to +60°C (-4°F to +140°F)

Temperature Mode

Spot: 12
Line: 12
Area: 12
Support 12 rules simultaneously

Video and Audio

Video Compression

H.265/H.264M/H.264H/H.264B/MJEPG

Resolution

Main stream:

(1280 × 1024/1280 × 720/640 × 512/), 1280 x 1024 by default;

Sub stream: (640 × 512/320 × 256), 640 × 512 by default

Frame Rate

50Hz:

Main Stream: 1fps–25fps, 25fps by default; sub stream: 1fps–25fps, 15fps by default
60Hz:

Main Stream: 1fps–30fps, 30fps by default; sub stream: 1fps–30fps, 15fps by default

Audio Compression

G.711a; G.711mu; PCM

General Function

Network Protocol

HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP

Region of Interest (ROI)

Yes

Edge Storage

FTP; Micro SD card (256G)

Interoperability

ONVIF; CGI; DAHUA SDK

Browser

IE: IE9 and the later (Edge not support)
Google: 42 and the earlier
Firefox: 52 and the earlier

User/Host

20 channels at most (the total bandwidth 64M)

Security

Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access

User Management

Support 20 users at most and users are classified as two groups-administrator group and user group.

Malfunction Detection

Network disconnection; IP addresses conflict; SD card error (status or storage space)

Certification

Certifications

CE; FCC

Port

Analog Video Output

1 channel of CVBS output with BNC port

Network

1 10M/100M Ethernet port (RJ-45)

Audio Input

1

Audio Output

1

Alarm Input

2

Alarm Output

2

RS-485

1 pair

Power

Power Supply

12V±20% DC, 1.2A, PoE (802.3af), ePoE

Power Consumption

Basic: 5.0W

Maximum: 13W (power adapter excluded)

Environment

Operating Temperature

-40°C to +70°C (-40°F to +158°F)

Operating Humidity

≤ 95%

Self-Adaptive

Auto heating to protect the chip under the cold environment

Physical Characteristics

Protection Grade

IP67, anti-surge 6KV, anti-elctrostatic 8KV (touched by objects), anti-elctrostatic 15KV (air)

Product Dimensions (L × W × H)

291 mm × 103.7 mm × 97 mm(11.46" × 4.06" × 3.82")

Packaging Dimensions (L × W × H)

365 mm × 175 mm × 176 mm (14.37" × 6.89" × 6.93")

Net Weight

≤1.4 kg (3.09 lb)

Gross Weight

≤1.9 kg (4.19 lb)

Lens

Contained

Power Adaptor

Selectable
