Detector Type

Vanadium Oxide Uncooled Focal Plane Detector

Max. Resolution

400 × 300

Pixel Pitch

17μm

Spectral Range

8μm–14μm

Thermal Sensitivity (NETD)

≤ 40mK@f/1.0

Focal Length

7.5 mm

13 mm

25 mm

H: 53.7° ×

V: 39.7°

H: 30° ×

V: 22.6°

H: 15.5° ×

V: 11.6°

Human (1.8 m × 0.5 m)

D: 221 m

(725.07 ft)

R: 57 m

(187.01 ft)

I: 28 m

(91.86 ft)

D: 382 m

(1253.28 ft)

R: 98 m

(321.52 ft)

I: 49 m

(160.76 ft)

D: 735 m

(2411.42 ft)

R: 189 m

(620.08 ft)

I: 95 m

(311.68 ft)

Vehicle (4.0 m × 1.4 m)

D: 558 m

(1830.71 ft)

R: 147 m

(482.28 ft)

I: 74 m

(242.78 ft)

D: 1020 m

(3346.47 ft)

R: 255 m

(836.61 ft)

I: 127 m

(416.67 ft)

D: 1961 m

(6433.73 ft)

R: 490 m

(1607.61 ft)

I: 245 m

(803.81 ft)

Enhancement (DDE)

Electronic Image Stabilization

19×

Auto; Manual

2D NR; 3D NR

90°/180°/mirror

Fire Detection & Alarm
Cold & Hot Spot Trace

Tripwire & Intrusion
Human & Vehicle Classification

Low Temperature Mode: -20°C to +150°C (-4°F to +302°F)
High Temperature Mode: 0°C to +550°C (+34°F to +1022°F)

Max (±2°C, ±2%)
Operating Temperature: -20°C to +60°C (-4°F to +140°F)

Spot: 12
Line: 12
Area: 12
Support 12 rules simultaneously

H.265/H.264M/H.264H/H.264B/MJEPG

Main Stream: SXGA (1280 × 1024)/960P (1280 × 960)/720P (1280 × 720)/400 × 300, 1280 × 960 by default
Sub Stream: 640 × 512/640 × 480/400 × 300, 400 × 300 by default

50Hz:

Main Stream: 1fps–25fps, 25fps by default; sub stream: 1fps–25fps, 15fps by default
60Hz:

Main Stream: 1fps–30fps, 30fps by default; sub stream: 1fps–30fps, 15fps by default

G.711a; G.711mu; PCM

HTTP; HTTPS; TCP; ARP; RTSP; RTP; UDP; RTCP; SMTP; FTP; DHCP; DNS; DDNS; PPPOE; IPv4/v6; SNMP; QoS; UPnP; NTP

Yes

FTP; Micro SD card (256G)

ONVIF; CGI; DAHUA SDK

IE: IE9 and the later (Edge not support)
Google: 42 and the earlier
Firefox: 52 and the earlier

20 channels at most (the total bandwidth 64M)

Authorized username and password; attached MAC address; encrypted HTTPS; IEEE 802.1x; controlled network access

Support 20 users at most and users are classified as two groups-administrator group and user group.

Network disconnection; IP addresses conflict; SD card error (status or storage space)

CE; FCC

1 channel of CVBS output with BNC port

1 10M/100M Ethernet port (RJ-45)

1

1

2

2

1 pair

12V±20% DC, 1.2A, PoE (802.3af), ePoE

Basic: 5.0W

Maximum: 13W (power adapter excluded)

-40°C to +70°C (-40°F to +158°F)

≤ 95%

Auto heating to protect the chip under the cold environment

IP67, anti-surge 6KV, anti-elctrostatic 8KV (touched by objects), anti-elctrostatic 15KV (air)

291 mm × 103.7 mm × 97 mm(11.46" × 4.06" × 3.82")

365 mm × 175 mm × 176 mm (14.37" × 6.89" × 6.93")

≤1.4 kg (3.09 lb)

≤1.9 kg (4.19 lb)

Contained

Selectable
