Camera

Image Sensor

1/1.8" CMOS

Pixel

8 MP

Max. Resolution

3840 (H) × 2160 (V)

ROM

8 GB

RAM

4 GB

Electronic Shutter Speed

1/1 s–1/30,000 s

Scanning System

Progressive

Min. Illumination

Color: 0.005 lux@F1.4
B/W: 0.0005 lux@F1.4
0 lux (IR light on)

Illumination Distance

500 m (1,640.42 ft) (IR)

Illuminator On/Off Control

Zoom Prio; Manual; Smart IR; Off

Illuminator Number

10 (IR)

Wiper

Smart wiper

Lens

Focal Length

5.6 mm–223 mm

Max. Aperture

F1.4–F4.5

Field of View

H: 61.8°–2.2°; V: 36.3°–1.3°; D: 69.2°–2.4°

Optical Zoom

40×

Focus Control

Auto; semi-auto; manual

Close Focus Distance

0.5 m–2 m (1.64 ft–6.56 ft)

Iris Control

Auto

DORI Distance

Detect

Observe

Recognize

Identify

3,030 m (9,940.94 ft)

1,204 m

(3,950.13 ft)

606 m

(1,988.18 ft)

303 m

(994.09 ft)

PTZ

Pan/Tilt Range

Pan: 0° to 360° endless
Tilt: –30° to +90°, auto flip 180°

Manual Control Speed

Pan: 0.1°/s–240°/s
Tilt: 0.1°/s–100°/s

Preset Speed

Pan: 240°/s; Tilt: 120°/s

Preset

300

Tour

8 (up to 32 presets per tour)

Pattern

5

Scan

5

Power-off Memory

Yes

Idle Motion

Pattern; Preset; Scan; Tour

PTZ Protocol

DH-SD
Pelco-P/D (Auto recognition)

Intelligence

Illegal Parking Capture

Radius of capturing area: 160 m (524.93 ft) (multi-scene), 65 m (213.25 ft) (single-scene)
Supports configuring and monitoring up to 8 illegal parking areas under the same scene; adaptive multi-scene tour is available to expand the monitoring area; supports recognizing motor vehicle attributes such as vehicle type, vehicle color, plate number and plate color

Checkpoint Capture

Detects events for up to 3 lanes.
Detects wrong-way driving and traffic congestion.
Recognizes motor vehicle attributes, including license plates, plate color, vehicle color, and vehicle type.

E-police

Detects events for up to 3 lanes.
Detects wrong-way driving.
Recognizes motor vehicle attributes, including license plates, plate color, vehicle color, and vehicle type.

Traffic Event

Detects pedestrian events on highways, elevated highways, express roads and more.

Video

Video Compression

H.264H; H.264B; Smart H.265+; H.264; H.265; MJPEG(Sub Stream); Smart H.264+

Streaming Capability

3 streams

Resolution

4K (3840 × 2160); 4M (2560 × 1440); 1080P (1920 × 1080); 1.3M (1280 × 960); 720P (1280 × 720); D1 (704 × 576); VGA (640 × 480); CIF (352 × 288)

Video Frame Rate

Main stream: 4K/4M/1080p/1.3M/720p (1–25/30 fps)
Sub stream 1: D1/VGA/CIF (1–25/30 fps)
Sub stream 2: 1080p/1.3M/720p (1–25/30 fps)

Bit Rate Control

CBR/VBR

Video Bit Rate

H.264: 512 kbps–16,384 kbps
H.265: 256 kbps–10,240 kbps

Day/Night

Auto (ICR)/Color/B/W

BLC

Yes

WDR

120 dB

HLC

Yes

White Balance

Auto; indoor; outdoor; tracking; manual; auto sodium lamp; sodium lamp; auto outdoor

Gain Control

Auto; manual

Noise Reduction

2D NR; 3D NR

Motion Detection

Yes

Region of Interest (RoI)

Yes

Image Stabilization

Electronic image stabilization

Defog

Optical

Digital Zoom

16×

Image Rotation

180°

Privacy Masking

Up to 24 areas can be set, with up to 8 areas in the same view

S/N Ratio

≥ 55 dB

Audio

Audio Compression

G.711a; G.711mu; G.726; G722.1; G.729; MPEG2-Layer2; G723; PCM

Network

Network Port

RJ-45 (10/100 Base-T)

Network Protocol

UDP; TCP; FTP; IGMP; RTMP; IPv6; IPv4; DNS; HTTP; PPPoE; NTP; DHCP; RTP; SMTP; 802.1x; Qos; HTTPS; SNMP; RTSP; DDNS; UPnP; ICMP

Interoperability

CGI; ONVIF (Profile S&G&T)

Streaming Method

Unicast/Multicast

User/Host

20 (total bandwidth: 64 M)

Storage

FTP; Micro SD card (512 GB)

Browser

IE 9 and later versions
Chrome 41 and later versions
Firefox 50 and later versions
Safari 10 and later versions

Management Software

Cyber City

Port

Analog Output

1 channel (CVBS output, BNC)

RS-485

1 (baud rate: 1200 bps–9600 bps)

Two-way Audio

Yes

Alarm Linkage

Capture; preset; tour; pattern; recordings on SD card; alarm digital input; send email; client E-map

Alarm Event

Motion/tampering detection; audio detection; network disconnection detection; IP conflict detection; encoder state detection; memory card state detection; memory space detection; power fault detection

Alarm I/O

7/2

Audio I/O

1/1

Power

Power Supply

36 VDC, 2.23 A±25% HI-PoE

Power Consumption

Basic: 20 W
Max.: 33 W (IR light on)

Environment

Operating Temperature

–40 °C to +70 °C (–40 °F to +158 °F)

Operating Humidity

≤ 95%

Protection

IP67, TVS 6000V lightning proof; surge protection; voltage transient protection

Structure

Product Dimensions

415.9 mm × Φ262.0 mm (16.37" × Φ10.31")

Net Weight

8.5 kg (18.74 lb)

Gross Weight

12.5 kg (27.56 lb)

Accessory

Included:
Wall mount bracket: PFB306W
Power adapter: PFM311B-030-EN-HKA
Optional:
Mount adapter: PFA118
Wall mount: PFB306W
Ceiling mount: PFB306W+PFA150
