Dahua NVR5216-16HP-XI/Pro 16CH 1U 16PoE WizMind Network Video Recorder
Most orders ship within 30 working days. Stock status shown on this page is not real-time.
After you place your order, please check the order confirmation email from our team. We will confirm stock, lead time and shipping before dispatch. If an item is out of stock, we may propose a compatible replacement model for your approval.
Working to a project deadline? Contact us before ordering.
Our team can confirm specifications, stock and pricing before you order.
Email sales@icctvzone.com or contact us.
Couldn't load pickup availability
Need help choosing the right model? I can confirm specifications, stock and lead time before you order.
NVR5216-16HP-XI/Pro
16CH 1U 16PoE 2HDDs WizMind Network Video Recorder
Key Points
- Max. Decoding Capability: 40 × 1080p@30 fps
- Max. 512/512/384 Mbps Incoming/Recording/Outgoing Bandwidth
- 8 Bays. Each HDD Storage Capacity Up to 20TB
- With AcuPick Camera Supports Up to 32-ch WizSeek & AcuPick
- AI by Recorder: 8-ch Face Detection and Recognition, 16-ch Perimeter Protection, 8-ch Video Metadata, 8-ch AcuPick
- 8K HDMI Output
Specifications
System
| Main Processor | Industrial-grade processor |
| Operating System | Embedded Linux |
| Operating Interface | Web, Local GUI |
AI
| AI by Recorder | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; AcuPick; WizSeek; Texted-Defined Alarming |
| AI by Camera | Face detection; face recognition; video metadata (human, motor vehicles, and non-motor vehicles); perimeter protection; SMD; stereo analysis; crowd distribution; people counting; ANPR; heat map; PPE detection; AcuPick |
AcuPick Performance (1080P)
| AI by Recorder (Xinghan enabled) | 8 channels |
| AI by Recorder (Xinghan disabled) | 16 channels |
| AI by Camera | All channels (36 targets/s) |
WizSeek
| Performance | 1. Compatible with cameras that support AcuPick, it can meet full-channel WizSeek. 2. Compatible with normal cameras, after enabling AcuPick by NVR, it can offer up to 8-channel WizSeek. 3. Modeling capability: up to 432,000 targets per day |
| Search Language | English; TradChinese; Korean |
Perimeter Protection
| AI by Recorder | 16 channels, 10 IVS rules for each channel |
| AI by Camera | All channels (32 targets/s) |
Face Detection
| Face Attributes | 6 attributes |
| AI by Recorder (Xinghan enabled) | 8 channels (up to 12 face images/s each channel) |
| AI by Recorder (Xinghan disabled) | 16 channels (up to 12 face images/s each channel) |
| AI by Camera | All channels (32 targets/s) |
Face Recognition
| Face Database Capacity | Up to 20 face databases with 200,000 images, total capacity 44 G |
| Recognition Performance (Recorder) | 16-channel FD (camera) + FR (recorder), 32 face images/s Xinghan enabled: 8-ch FD+FR, 16 face images/s Xinghan disabled:16-ch FD+FR,16 face images/s |
| AI by Camera | All channels (32 targets/s) |
SMD
| SMD Plus by Recorder | Xinghan enabled: Not support Xinghan disabled:16 channels human/vehicle filtering |
| SMD by Camera | All channels (64 targets/s) |
Video Metadata
| AI by Recorder | Xinghan enabled:8ch,23 attributes Xinghan disabled:16ch,23 attributes |
| AI by Camera | All channels (32 targets/s) |
| People Attributes | 9 human body attributes |
| Motor Vehicle Attributes | 9 attributes |
| Non-motor Vehicle Attributes | 4 attributes |
Vehicle License Plate Comparison
| ANPR by Camera | All channels (32 targets/s) |
| License Plate Database | Up to 20,000 plate numbers; Blocklist & allowlist |
Audio and Video
| Access Channel | 16 channels |
| Network Bandwidth | AI disabled:512Mbps incoming/512Mbps recording/384Mbps outgoing AI enabled:200Mbps/200Mbps/200Mbps |
| Resolution | 32MP;24MP;16MP;12MP;8MP;6MP;5MP;4MP;3MP;1080p;720p;960p;D1;CIF;QCIF |
| Decoding Capability | AI disabled: up to 16-ch 5MP@30fps AI enabled: up to 16-ch 1080p@30fps |
| Video Output | 1 VGA, 1 HDMI VGA:1920×1080 etc. HDMI:8K/4K/1080P |
| Multi-screen Display | Main/Sub screen:1/4/8/9/16 |
| Third-party Camera |
Order & Pricing Information for Surveillance Products
Please note the following important details when ordering surveillance products from ICCTVZONE:
- Order confirmation: After you place an order, please check the confirmation email from our team. We will confirm stock, lead time and shipping before dispatch.
- Stock & replacements: Inventory status is not real-time. If an item is out of stock, we may propose a compatible replacement model for your approval.
- Final pricing: Prices shown are indicative. The final price is confirmed on the Proforma Invoice (PI) after order confirmation.
- Project-specific pricing: Some products are configured for project requirements; pricing may vary with quantity and specification.
- Minimum order: A minimum order value may apply to non-stock or project items; our team will confirm before processing.
- Shipping costs: Shipping is calculated separately and added to the order total.
- Duties & taxes: Import duties, taxes and customs clearance fees are not included in the product price or shipping quote. These charges are the customer's responsibility.
- Genuine products: We supply genuine products from leading brands with current firmware.
- Technical support: Our engineers provide pre-sales and after-sales technical support.
- Warranty: Warranty terms depend on the product and order type; we will confirm the applicable coverage in writing.
Questions? Contact sales@icctvzone.com.
Product Features
What this model is for, what it does well, and what to confirm before it goes on a project.
Medium to large PoE surveillance deployments that need on-board AI analytics such as face recognition, perimeter protection and AcuPick search.
Run face detection, perimeter protection and video metadata directly on the recorder to cut server load and speed up investigations.
512 Mbps incoming, recording and outgoing bandwidth keeps many high-resolution streams flowing without dropping frames.
Sixteen PoE ports with ePoE support simplify camera cabling and extend reach where standard PoE struggles.
