Home » Dahua SG1024 24-Port Unmanaged Gigabit Ethernet Switch
DAHUA SG1024 24-Port Unmanaged Gigabit Ethernet Switch
DAHUA SG1024 24-Port Unmanaged Gigabit Ethernet Switch
DAHUA SG1024 24-Port Unmanaged Gigabit Ethernet Switch
DAHUA SG1024 24-Port Unmanaged Gigabit Ethernet Switch
icctvzone

Dahua SG1024 24-Port Unmanaged Gigabit Ethernet Switch

In stock
SKU: SG1024
$9,999.99
Lead time & order confirmation

Most orders ship within 30 working days. Stock status shown on this page is not real-time.

After you place your order, please check the order confirmation email from our team. We will confirm stock, lead time and shipping before dispatch. If an item is out of stock, we may propose a compatible replacement model for your approval.

Working to a project deadline? Contact us before ordering.

Need help with this product?

Our team can confirm specifications, stock and pricing before you order.

Email sales@icctvzone.com or contact us.
Authentic productsGenuine brands, traceable supply
Worldwide shippingTracked delivery to 200+ countries
Technical supportPre-sales and after-sales help
Daniel Levent
Daniel LeventSenior Engineer SalesOnline now

Need help choosing the right model? I can confirm specifications, stock and lead time before you order.

Email meContact us

SG1024

24-Port Unmanaged Gigabit Ethernet Switch

> 24-Port 10/100/1000Mbps Ethernet Switch.

> Complies with IEEE802.3, IEEE802.3ab, IEEE802.3u and IEEE802.3X standards.

> Supports MAC learning and aging and MAC address list capacity is 8K.

> Wide operating temperature from -20°C to +60°C.

> Metal housing with great heat dissipation. Easy to install, and plug and play.


Hardware

Included Power Adapter



Yes

Ethernet Port



24

Ethernet Port Speed



10/100/1000 Mbps

Ethernet Port Uplink Speed



10/100/1000 Mbps

Description of Function Slots



Port 1-22: 22 × RJ-45 10/100/1000 Mbps;

Port 23-24：2 × RJ-45 10/100/1000 Mbps(Uplink)

Power Supply



Built-in power supply: 100–240 VAC, 50/60 Hz, max 0.7 A

Operating Temperature



–20 °C to +60 °C (–4 °F to +140 °F)

Storage Temperature



–40 °C to +75 °C (–40 °F to +167 °F)

Power Consumption



Idling: 7.5 W;

Full load: 11.0 W

Storage Humidity



10%–90% (RH), non-condensing

Basic

Operating Humidity



10% –90% (RH), non-condensing

Performance

Management Type



No

Switching Capacity



48 Gbps

Packet Forwarding Rate



35.71 Mpps

Packet Buffer Size



4 Mbit

Jumbo Frame



15K Byte

MAC Table Size



8K

Communication Standard



IEEE802.3; IEEE802.3ab; IEEE802.3u; IEEE802.3X

Feature

Link Aggregation



Yes

General

Statics Protection



Air discharge: 8 kV;

Contact discharge: 6 kV

Lightning Protection



Common mode: 2 kV;

Differential mode: 0.5 kV

Net Weight



1.72 kg (3.79 lb)

Gross Weight



2.63 kg (5.80 lb)

Product Dimensions



440 mm × 155 mm × 43.7 mm (17.32" × 6.10" × 1.72") (L × W × H)

Packaging Dimensions



523 mm × 273 mm × 109 mm (20.59" × 10.75" × 4.29") (L × W × H)

Casing Material



Iron

Installation



Desktop mount; rack mount

Certifications



CE

Order & Pricing Information for Surveillance Products

Please note the following important details when ordering surveillance products from ICCTVZONE:

  • Order confirmation: After you place an order, please check the confirmation email from our team. We will confirm stock, lead time and shipping before dispatch.
  • Stock & replacements: Inventory status is not real-time. If an item is out of stock, we may propose a compatible replacement model for your approval.
  • Final pricing: Prices shown are indicative. The final price is confirmed on the Proforma Invoice (PI) after order confirmation.
  • Project-specific pricing: Some products are configured for project requirements; pricing may vary with quantity and specification.
  • Minimum order: A minimum order value may apply to non-stock or project items; our team will confirm before processing.
  • Shipping costs: Shipping is calculated separately and added to the order total.
  • Duties & taxes: Import duties, taxes and customs clearance fees are not included in the product price or shipping quote. These charges are the customer's responsibility.
  • Genuine products: We supply genuine products from leading brands with current firmware.
  • Technical support: Our engineers provide pre-sales and after-sales technical support.
  • Warranty: Warranty terms depend on the product and order type; we will confirm the applicable coverage in writing.

Questions? Contact sales@icctvzone.com.
Why this model

Product Features

What this model is for, what it does well, and what to confirm before it goes on a project.

Best for

Distributing gigabit network connectivity to IP cameras and recorders in a small to mid-size surveillance deployment.

Before you orderConfirm your rack space and total device count against the 24 ports, and check current lead time and stock with ICCTVZONE before ordering.
01
24 Gigabit Ports

Twenty-four 10/100/1000 Mbps RJ-45 ports give you plenty of connections for cameras, NVRs and workstations on one switch.

02
Plug and Play

Unmanaged operation means no configuration is needed, so you can power up and start connecting devices right away.

03
Built for Tough Sites

A metal housing with wide -20°C to +60°C operating range supports reliable use in demanding installation environments.
